Strong powerful best price fused wire drawing machine
Description of fused wire drawing machine:
The pulley type continuous wire drawing machine has the characteristics of simple structure, low cost, and easy operation, and it is suitable for drawing a variety of medium and thin fiber material, especially for mild steel wire, galvanized iron wire, steel head wire, stainless steel wire, rubber hose steel wire, spring steel wire, rod welding wire and copper wire aluminum rod, etc.
Scope of application: gas-protection welding wire, welding electrode, stainless steel wire, galvanized iron wire, bullet and hard wire, copper wire, and metal product wire, etc.
Structure of fused wire drawing machine:
The equipment consists of main reduction box.die casing, wheel frame, sash brace and electrical control system. The spinning drawing blocks are driven by JZT series motor, with gear coupling runs changeful gears to reduce speed. The drawing blocks are vertically fixed in sealed box body. The gear pairs are lubricated with oil.
In order to lower residual heat on the surface of the block, the cooling means is installed in interval of the block. To reduce its working temperature, the machine is soaked in cooling water.
The machine runs with carvel or linkage. The safety halt gear is installed by the position of operating block.
Transmission System: Strong narrow joint V-belt; strong narrow joint V-belt and spiral bevel gear; strong narrow joint V-belt + standard gear box transmission.
Mode of speed: adjustment AC frequency conversion control
Pay-off Method: Pay-off machine or spool pay-off machine
Take-up Method: I-Spool take-up machine or trunk pay off machine
Material: Suitable for Drawing Welding rod; welding Wire (gas protection welding wire and submerged arc welding wire); steel wire (medium, low carbon steel wire, stainless steel wire); Wire and cable (copper wire, aluminum wire) and other metal wires
* Various combined drawing equipment can be designed according to the customers' requirements
parameters of fused wire drawing machine:
Items
Unit
LW9/560
LW11/560
LW8/450
Capstan diameter
mm
560
560
450
Max inlet diameter
mm
Φ6.5-5.5
Φ6.5
Φ2.6
Min outlet diameter
mm
Φ2.0-1.7
Φ1.5
Φ1.0
Inlet tensile strength
Mpa
<1150
<1150
<1150
Drawing speed
m/min
420
480
400
Drawing dies
time
9
11
8
Total compression rate
%
90.45
94.67
85.21
Average compression rate
%
22.97
23.4
21.25
Motor power
Kw
18.5-30
15-30
7.5-11
Pictures of fused wire drawing machine:
Flow Chart
1. We have gotten ISO9001:2008 standard and certificate
2. Company established year: 1985
3. Company location: Wuxi city, 125km away from Shanghai
4. FOB port: Shanghai
5. Business type: Manufacturer
6. Number of employees: 100-200
7. Welcome to visit us, we will pick you up at Shanghai airport or other place near Wuxi
Our services:
1. We are always providing customers with not only the excellent solutions of steel wire production line, best related equipment and perfect services but also free technical services on the steel wire production line.
2. If you have any questions in the process of producing steel wire, or about steel wire production line, please feel free to contact us any time. Our solutions and quotation will be sent to you soon to meet you special requirements.
3. Welcome to visit our factory and Wire drawing production lines.
--------------------------------------------------------------------------
Successful experience / Markets:
Be up to the international level. Our lines and related complete equipment have been exported to Southeast Asia, West Asia, Eastern Europe, South America, the Middle East, Russia, India, Indonesia, Morocco, South Africa, Algeria, etc.
fused wire drawing machine
