Energy Saving Ice Cube Machine 10tons per Day

Specifications

1,Output: 10000KG in 24hours
2,Size of ice : 22mm*22mm*22mm or 29mm*29mm*22mm
3,Special ice outlet:semi-automatic function.

Commercial ice cube machine is used for producing ice cube which is edible ice often used to mix with drinks in restaurants, hotels, wine bars etc.

It has been adopted four leading technologies: automatically adjust ice thickness, automatically match the change of ambient temperature, automatically supply ice making water and facilitate condensing pressure steady. With the full automatic production process, our cube ice maker machine can produce ice cube with nice appearance and adjustable thickness.

The production of our cube ice maker machine can reach 90% to 95% in summer. When the environment temperature is below 23°C, the production of our cube ice maker machine can reach 100% to 130%.
Low Power Consumption: Our cube ice maker machine features lower power consumption. The power consumption of our cube ice maker machine only reaches about 75KW.H to 85KW.H for producing 1 ton ice cube. When the environment temperature is below 23°C, the power consumption of our cube ice maker machine is from 70KW.H to 80KW.H.

Optional Equipment: Our cube ice maker machine can be equipped with automatic ice spreading system and special ice packing system. The cube ice maker machine not only can reduce manpower, but also can ensure the food security, meet the food standard and improve the production capability.

Installation: For water cooled system: just need assemble the cooling tower, connect the water pipes between the ice cube machine and cooling tower and supply the power and water to the machine as our installation manual required.

For air cooled system: the air cooled condenser is with the machine in one whole unit, we already did the connection in our factory, so customer just need supply the power and water to the machine as the installation manual required.

 Ice Cube Maker Machine models for your reference:

Item No.	Production	Compressor Rated Power	Circulating Water Pump Power	Cooling Water Pump Power	Cooling Fan Power	Machine Dimension	Weight of Machine
	Ton/24H	KW	KW	KW	KW	L*W*H	KG
CV1000	1.0	3.69	0.37	1.5	0.37	1200*1000*1600	800
CV2000	2.0	7.11	0.37	1.5	0.55	1630*1600*1686	1000
CV3000	3.0	9.68	0.37	2.2	0.75	1980*1630*1840	1200
CV5000	5.0	17.47	0.55	2.2	1.5	2890*1780*1840	1600
CV8000	8.0	28.52	1.1	4	1.5	4820*1780*2000	2500
CV10000	10.0	37.68	1.1	4	1.5	5730*1780*2000	3000
CV15000	15.0	52.41	1.65	5.5	2.2	8620*1780*2000	4500
CV20000	20.0	75.36	2.2	8	3	11460*1780*2100	6000
