Home > Industrial Equipment & Components > Valve > Ball Valve > Motorized Butterfly Valve

Motorized Butterfly Valve

Name: Motorized Butterfly Valve
Brand: LAPAR
SKU: 114162325

US$ 10 - 200 MOQ: 1 Set

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Structure:

Butterfly

Pressure:

Medium Pressure

Contact Supplier Request Quote Chat Now

Shanghai Lapar Control Valve Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Hongkong China base ports

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Structure Butterfly

Pressure Medium Pressure

Power Solenoid

Material Stainless Steel

Temperature of Media Normal Temperature

Media Oil

Port Size DN40~DN1600mm

Place of Origin Shanghai, China

Model Number LPB11

Brand Name LAPAR

Specifications

Motorized Butterfly valve made by italy Lapar valve, adjustable motorized Butterfly valves, modifiable motorized butterfly valve

Motorized Butterfly valves, On/off Motorized Butterfly Valve, Motorized Modulating Butterfly Valve, Wafer Motorized Butterfly Valve

LPB11 Motorized butterfly Valve has unique shape, compact structure, high-strength disc using frame structure. It has bidirectional sealing function for installation without the interference of the medium flow direction. The surface is coated with epoxy resin, which could prevent rust effectively, a wide choice of seat material can be used in different medium, such as water, oil…

Design Feature

Optional multi-pressure stage
Special design will not cause death card
Torque and lighter, easy to replace the seat
Unique shape
Frame structure
Coated disc

Parameter of motorized butterfly valve

Actuator	Electric, Pneumatic, Handwheel, Handle
Control	On-off, Modulating, Inteligent
DN	40~1200mm
Pressure	1.0~2.5Mpa
Temperature	EPDM: -29~120°C, FPM: -29~150°C EPT: -20~140°C, CR: -29~80°C NBR: -29~80°C, SI: -29~200°C
Connection	Flange, Wafer
Structure	A Type, LT Type
Body Material	SS316L, SS316, SS304, SS304L, WCB, Casting Iron, Ductile Iron
Disc Material	SS316L, SS316, SS304L, Casting Iron, WCB, B148, Ductile Iron+Nylon 11, CE3MN
Seat Material	NBR, EPDM, EPT, FPM, CR, SI
Medium	Water, Liquid
Option	Limit Switch, Positioner, Solenoid Valve, Pressure-relief Valve

Motorized Butterfly valves, A type Motorized Butterfly Valve, Lug type Motorized Butterfly Valve

Design standard:

Valve body is designed to meet ISO 5752.

Upper flange standard:

24” and below, valve mounting flange and stem shall be per ISO 5211.

28” and above, valve mounting flange shall be per ISO5211, stem shall be round keyed.

Flange standard:

LPB11: ASNI 150 B16.5, JIS B2211, GB 9113.1

All wafers have locating holes for ease of installation.

Pressure rating:

Bi-directional bubble-tight shut off to: 16 bar (230PSI) – DN40~DN600mm

10 bar (150PSI) – DN650~DN1200mm

And tested to 110% of full rating: 18 bar (260PSI) – DN40~DN600mm

11 bar (160PSI) – DN650~DN1200mm

Shell testing:

The body strength can stand 150% of full rating: 24 bar (340PSI) – DN40~DN600mm

15 bar (220PSI) – DN650~DN1200mm

Installation instruction:

The valve is designed for using between all types of flat or raised face flange, do not use flange gaskets. For proper installation, the space between flanges must be sufficient to permit valve insertion without disturbing the rubber liner flange seal. Rotate the stem to position the disc within the body, place the valve between flanges and hand-tighten the bolts. Slowly open the valve counter clockwise to check for adequate disc clearance. Rotate the disc to 10% open position and cross tighten all bolts again check for adequate disc clearance.

Stem retaining mechanism:

The stem is retained in the body through a special Q type design when the size is under DN350mm, so the stem can be removed from the body and disc without any special tools. Only when being disassembled, the valve disc can be positioned around 135º.

Others:

According to customer requirements.
