high temperature white color ptfe tape

Specifications

ptfe tape
1.Manufacturer&Exporter
2.Professional in PTFE Coating
3.Chinese Largest Production Base

High temperature PTFE/Teflon Adhesive Tape:

PTFE coated glass fabric provide dimensional stability, high tensile strength and edge tear, operates over a temperature range from -100° F to +500° F (- 70° C to +260° C), and offers better abrasion resistance than uncoated glass cloth. The PTFE surface offers quick release and chemical resistance characteristics. Anti- static PTFE glass yields improved thermal conductivity and static dissipation. Available with silicone or acrylic adhesives, PTFE glass applications include heat sealing and low friction release surface liners for conveyors.

Technical Parameters:

	TYPICAL PROPERTIES
TAP-G Series	Backing Thickness (mm)	Adhesive Thickness (mm)	Total Thickness (mm)	Adhesive Strength (N/cm)	Tensile Strength (N/cm)	Temperature Resistance (°C)
TAP-G08	0.08	0.05	0.13	5.3	180.2	-73~260
TAP-G11	0.11	0.05	0.16	5.6	210.5	-73~260
TAP-G13	0.13	0.05	0.18	6.2	230.3	-73~260
TAP-G15	0.15	0.05	0.20	6.3	240.2	-73~260
TAP-G18	0.18	0.05	0.23	6.9	310.3	-73~260
TAP-G20	0.20	0.05	0.25	7.2	350.3	-73~260
TAP-G25	0.25	0.05	0.30	7.4	420.4	-73~260
TAP-G35	0.35	0.05	0.40	7.6	450.2	-73~260

Features&Benefits:

Perfect for extreme temperature applications, silicone adhesives perform in continuous operating temperatures from -73°C/-99F to +260°C/500F

Excellent chemical resistance, mechanical and electrical properties and remove cleanly after use

Acrylic adhesives perform in continous operating temperatures from -40°C/-40F to +188°C/370F

Exceptionally resistant to solvents

Excellent adhesion to metal and superior weathering and ageing characteristics

Excellent shelf life with increased tack and adhesion properties

Available in different thicknesses and PTFE coating levels

Different textures and anti-static versions available

Laminated, with multi -layer film versions available for ultimate performance

Applications:

· Packaging - Heat Sealer Tapes for covering various hot wire and platen sealing equipment

· Components - Electrical insulation on high temperature transformers, coils, motors as well as lay-up and insulation for components

· Textile - Covering of dryer cylinders

· Food processing - Lining chutes and guide rails

· PVC Welding - Covering metallic and RF welding platens

· Polymer processing - Lining on solvent recovery units and protective barrier on paper/film extrusion coating lines

· Industrial Splicing & Seaming - especially of other fluoropolymenr materials
