Specifications
VF Reductor1.Housing:Aluminium Alloy
2.ISO9001,Factoy price,OEM
3.Model:VF63,Ratio:7.5 to 100
4.Compact structure
Industrial Power Transmission Small Worm Gear VF Reductor
Specifiction:
| Type: | Worm Gear Speed Reducer | ||||||||
| Model: | VF063 |
||||||||
| Ratio: | 1:7.5,10,15,20,25,30,40,50,60,80,100 | ||||||||
| Color: | Blue/Silver Or On Customer Request | ||||||||
| Material: | Housing: Die-Cast Aluminum Alloy | ||||||||
| Worm Gear-Copper-10-3# | |||||||||
| Worm-20CrMn Ti with carburizing and quenching, surface harness is 56-62HRC | |||||||||
| Shaft-chromium steel-45# | |||||||||
| Packing: | Carton and Wooden Case | ||||||||
| Bearing: | C&U Bearing | ||||||||
| Seal: | NAK SKF | ||||||||
| Warranty: | 1 Year | ||||||||
| Input Power: | 0.37KW,0.55KW,1.1KW,1.5KW |
||||||||
| Usages: | Industrial Machine: Food Stuff, Ceramics,CHEMICAL,Packing,Dyeing, Woodworking,Glass. |
||||||||
| IEC Flange: | 71B5,71B14,80B5,80B14,90B5,90B14 |
||||||||
| Lubricant: | Synthetic&Mineral | ||||||||
Permitted Output Torque:
| Ratio | Model | |||||||
| 030 | 040 | 050 | 063 | 075 | 090 | 110 | 130 | |
| 7.5 | 18 | 40 | 71 | 128 | 185 | 290 | 480 | 750 |
| 10 | 18 | 40 | 72 | 130 | 195 | 310 | 520 | 820 |
| 15 | 18 | 40 | 74 | 140 | 200 | 360 | 570 | 920 |
| 20 | 18 | 39 | 73 | 135 | 210 | 355 | 560 | 910 |
| 25 | 21 | 38 | 70 | 130 | 200 | 340 | 590 | 930 |
| 30 | 20 | 45 | 84 | 160 | 230 | 410 | 630 | 1040 |
| 40 | 18 | 41 | 76 | 145 | 220 | 360 | 610 | 1050 |
| 50 | 17 | 39 | 73 | 135 | 210 | 340 | 600 | 980 |
| 60 | 16 | 36 | 68 | 130 | 200 | 320 | 560 | 900 |
| 80 | 13 | 33 | 65 | 122 | 190 | 285 | 490 | 840 |
| 100 | 29 | 55 | 118 | 180 | 270 | 460 | 740 | |
Product Feature:
1.Compact structure, light size, small and high efficiency
2.Good funciation of heat exchange, rapid heat rejection
3.Easy installation aand flexible connecting style. Easy for maintaining and checking
4.Large in both transmission ratio and twisting distance resulting to a high capacity of bearing and loading
5.Widely application, little noise, long lasting
6.Widely applicable and liable
Process Of An Order:
1. Please check product detailed information above.
A. Model/Size B. Transmission Ratio C. Shaft Direction D. Order Quantity.
2. Our Export Service Team will contact you with a quotation file within 3 hours after our
team get your enquiry.
3. When you place an order, our team will confirm with you about color,
package,method of payment and delivery, then a sales contract will be sent to you to
confirm.
4. Packing: Carton and Wooden Case.
5. How to delivery:
By sea - Buyer appoint forwarder, or our sales team find suitable forwarder for
buyers.
By air - Buyer offer collect express account, or our sales team find suitable express
for buyers. (Mostly for sample)
Others - We arrange to delivery goods to some place in China appoint by buyers.
Welcome To Visit Our Factory - Located in the tourism city - Hangzhou -West Lake.
