Manufacturer DH-50 50VA Single Phase Power Transformer , Toroidal Transformer /

Manufacturer DH-50 50VA Single Phase Power Transformer , Toroidal Transformer / thumbnail-1
Manufacturer DH-50 50VA Single Phase Power Transformer , Toroidal Transformer / photo-1
US$ 10 - 30 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Yomin Transformer
Model Number:
DH-50 Transformer
Contact Supplier Request Quote Chat Now
Yueqing Yomin Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Yomin Transformer
Model Number DH-50 Transformer
Usage Power
Phase Single
Coil Structure Toroidal
Coil Number Autotransformer

Manufacturer DH-50 50VA power toroidal transformer

Model:DH-50

Manufacturer DH-50 50VA Single Phase Power Transformer , Toroidal Transformer /

Product Description

Toroidal Transformers offer many advantages over standard laminated power



transformers. Toroidals provide quiet, efficient operation with very low stray magnetic



fields. Their small size and weight support a package that is easy to design into any



application.



Advantages of Toroidal Transformer:

A toroidal transformer weighs about half as much as conventional transformer with the same capacity and heat rise. The main materials used in transformer are copper and steel, both of which are getting scarcer with cost increases as a consequence.No impregnation is needed to keep the laminates quiet so this potential environmental hazard is avoided.The toroidal transformer fits into a smaller space, which allows chassis plates and enclosures to be smaller with less material used.

Technical parameters



  • Capacity........................................................................50VA
  • Frequency.....................................................................50/60Hz
  • Max. Temperature........................................................60℃
  • Temperature Class......................................................Class B (130℃)
  • Voltage Combination...................................................Pls.see selection form.
  • Winding Material..........................................................100% Copper
  • Mounting Metal Disk....................................................Provided
  • Rubber Gasket.............................................................Provided
  • Standards................................................VDE0550,IEC204-1,IEC61588,EC439
  • Sample Service...........................................................Pay to Provide
  • Quality Assurance.......................................................24 months
  • Item Condition..............................................................Brand-New
Item Capacity Static Current Efficiency Voltage Combination

Case

Qty.
Model (VA) (mA) (%) Primary(V)/Secondary(V) (Pcs)
DH-50 50 10 90

230/24,220/24,230/36,

220/36,440/ 230,230/12,

130-240/15-240,115/24

 24
DH-100 100 15 92 24
DH-150 150 20 93 24
DH-200 200 30 94 24
DH-250 250 35 94 18
DH-300 300 40 94 18
DH-350 350 45 95 18
DH-400 400 50 95 18
DH-450 450 55 95 18
DH-500 500 55 95 18
DH-550 550 55 95 18
DH-600 600 55 95 18
DH-700 700 60 95 12
DH-800 800 65 95 12
DH-1000 1000 75 95 12
