2015 New Style ! computerized Horizontal Tensile Testing Machine/testing bed 100KN/200/KN/300KN/500KN
Features
• Tenson test bed employ a computer system.
• Automatic print out of test certificate with a diagram.
• Fully enclosed hydraulically operated auto protection cover for ultimate safety.
• The structure can be taken apart in sections for easy transport, completely modular.
• Extra control box for adjusting the piston position before testing.
• Limit switches for protecting the load cell.
• Measurement of elongation.
• The computer system based on WIN7 is installed with operator friendly software. Software is very easily operated with keyboard and mouse.
• The operator can select the different function (hold test, break test, proof test) by software.
• Testing speed and mend speed are adjustable by software.
• Testing diagram and data are displayed on the monitor in real time.
• Software will operate in English language
* Various comparison curves are available
• Load-elongation, Load-time, Stress-Elongation, Strain-time
* Multi-function selection
• Break test, Proof test, Hold test, Cycle test (not dynamic fatigue test)
• Accuracy:+/- 1% for the range 10-95% and +/- 1% for lower 10% range with secondary load cell (optional), will calibrate to ASTM E-4 or ISO 7500
• Computer, printer, color monitor and testing software is included as standard equipment.
Model
Model |
WLW-500 |
WLW-1000 |
WLW-2000 |
WLW-3000 |
WLW-5000 |
WLW-10000 |
WLW-20000 |
Load capacity (kN) |
500 |
1000 |
2000 |
3000 |
5000 |
10000 |
20000 |
Load capacity (Metric Ton) |
50 |
100 |
200 |
300 |
500 |
1000 |
2000 |
Accuracy |
±1% of reading value |
||||||
Effective testing length (meter), n is section |
6×n |
6×n |
6×n |
6×n |
6×n |
6×n |
12×n |
Max. piston stroke (mm) |
1000 |
1000 |
1500 |
1500 |
2000 |
2000 |
3000 |
Power supply |
3-phase, 380V±10%, 50Hz (customized made) |
||||||
Work environment |
10-30℃, Relative humidity≤80% |
||||||
