CDSL 5511 Integration Cheap Ultrasonic Sensors for Level Transmitter

Name: CDSL 5511 Integration Cheap Ultrasonic Sensors for Level Transmitter
Brand: FOXC
SKU: 114084497
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

FOXC

Model Number:

CDSL5511

Shanghai Xingshen Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name FOXC

Model Number CDSL5511

Specifications

1. non-contact ultrasonic level transmitter
2. reliable and cost-effective
3. stable performance
4. ultrasonic echo treatment

Features

The lasted microprocessor and unique Echo Discovery technology and False echo learn function make ultrasonic level gauge accurately identify true echo and get the precise measure result among numbers of false echoes.
Temperature sensor in the transducer detects the temperature in the vessel and compensates the influence of temperature on the signal running time.
SMD technology improves the products’ reliability.
D/A conversion enhance precision and resolution of electrical output.
Sensor covered with PTFE material, suitable for all kinds of corrosive applications.
Programmable relay output and high accuracy 4~20mA output

CDSL5511	Integration Ultrasonic Level Transmitter					Model
	A	two wire 4~20mA 0~3m				Output and measure range
	B	two wire 4~20mA 0~5m
	C	two wire 4~20mA 0~8m
	D	two wire 4~20mA 0~10m
	E	four wire 4~20mA 0~15m
	F	four wire 4~20mA 0~20m
		Y	measuring liquid level			Service
		W	measuring solid level
			N	standard product		Requirement
			F	anti-corrosion(PTFE lined)
			E	intrinsic safe
			H	with HART communication
				0	no switch output	Function options
				1	one switch output
				2	two switches output
						Measure range(mm)
