Specifications
1. magnetic level gauge with transmitter optional2.UPVC material
3. for acid and alkaline solvents at AMB temperature
UHZ-517C17 Corrosion Proof Magnetic Level Gauge is economical due to using UPVC fittings. The level gauge is suitable for measuring levels of acid and alkaline solvents but not for aromatic series, hydrocarbon, ketone and esters liquid applications.
Tri-magnet driven switches are optional. It is possible to realize upper/lower limit alarm and control of liquid level or interface. LB transmitter is also optional for 4~20mA output signals.
Disadvantage: easy aging outdoors.
Technique Parameter
Measure Range: |
300~6000mm (center distance) or on request. |
Nominal Pressure: |
PN1.0MPa |
Working Pressure: |
≤0.75MPa |
Working Temperature |
-20°C~60°C |
Medium Density |
800~2000kg/m³ |
Chamber(bypass tube) |
Φ63×4mm |
Process Connection |
Factory Standard: DN40 PN1.0MPa; Or on request |
Chamber/Flange/ Wetted Material |
Chamber: UPVC Wetted material: UPVC |
Magnetic Float |
Its size depends on liquid density Material: PP
|
Optional Items |
1. Tri-magnet level switch 2. Drain valves(UPVC ball valve) 3. Level Transmitter 4. Magnetostrictive level transmitter |
