Home > Electrical & Electronics > Power Supply & Distribution > Voltage Regulator > Manufacturer TDGC2-15 Single Phase Auto Voltage Regulator , Variac Suppliers 60A Output Regulator . Quality Choice
Manufacturer TDGC2-15 Single Phase Auto Voltage Regulator , Variac Suppliers 60A Output Regulator . Quality Choice
US$ 100 - 300
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Yomin Regulator
Model Number:
TDGC2-15
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manufacturer TDGC2-0.2 Single Phase Voltage Regulator Variac,Powerstat Variable Autotransformer 200VA/ Quality ChoiceUS$ 0.1 - 1MOQ: 1 Piece -
Manufacturer TDGC2-1 Single Phase Voltage Regulator ,Variac/Variable AC Output Regulator . Quality ChoiceUS$ 23 - 25MOQ: 1 Piece
-
Manufacturer TDGC2-2 Single Phase Voltage Regulator ,Variac Power Supply 2000VA /US$ 32 - 34MOQ: 1 Piece
-
Manufacturer TDGC2-3 Single Phase Voltage Regulator , Variac / Variable Transformer 3000VA . Quality ChoiceUS$ 39 - 41MOQ: 1 Piece
-
Manufacturer YMTSVC-30 Three Phase Servo Motor Stabilizer , Automatic Voltage Stabilizer 30KVA /US$ 100 - 300MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
Yomin Regulator
Model Number
TDGC2-15
Usage
Other
Phase
Single Phase
Current Type
AC
Manufacturer TDGC2-15 Single phase auto voltage regulator variac suppliers 60A output Model:TDGC2-15
Product Description
The Voltage regulators (Variac) are used to adjust the voltage from 0 volts up to
the maximum voltage for which they have been designed and among the most
usuall applications. No additional wave from distortion. The main applications are:
- Laboratory control equipment.
- Lighting equipment.
- Temperature controls.
- Motor speed control.
- Controlling of other transformers.
- Etc.
Manually Operated Rotary Knob to control output voltage, by means of a control
button on the shaft of the voltage regulator (Variac) which allows to act on the
brush and achieve the desired voltage. The voltage can be smoothly varied
between turns as the brush has a relatively high resistance (compared with a
metal contact) and the actual output voltage is a function of the relative area of
brush in contact with adjacent windings.
Technical parameters
- Capacity......................................................15000VA
- Output Current...........................................60A
- Output.........................................................0~250V AC
- Frequency..................................................50/60Hz
- Input............................................................220V AC
- Insulation Resistance...............................>5MΩ
- No. of Phase..............................................Single-Phase
- Winding Material.......................................100% Copper
- Max.Temperature......................................60℃
- Insulation Class.........................................Class B (130℃)
- IP/NEMA Rating..........................................IP20
- Variable Operation....................................Manually Operated Rotary Knob
- Portable Carrying Grip.............................Provided
- Pollution Rating.........................................Class III
- Analog Voltmeter Display........................Provided
- Housing Material.......................................Shock-Proof Metal
- Voltage Setting.........................................Manual Control
- Standards...............................................VDE0550,IEC204-1,IEC61588,EC439
- Sample Service........................................Pay to Provide
- Quality Assurance...................................18Months
- Item Condition.........................................Brand-New
| Item | Capacity | Input Voltage | Output Voltage | Output Current | Case Qty. |
| Model | (kVA) | (V) | (V) | (A) | (Pcs.) |
| TDGC2-0.2 | 0.2 | 220 | 0~250 | 0.8 | 12 |
| TDGC2-0.5 | 0.5 | 220 | 0~250 | 2 | 6 |
| TDGC2-1 | 1 | 220 | 0~250 | 4 | 4 |
| TDGC2-2 | 2 | 220 | 0~250 | 8 | 4 |
| TDGC2-3 | 3 | 220 | 0~250 | 12 | 2 |
| TDGC2-5 | 5 | 220 | 0~250 | 20 | 1 |
| TDGC2-7.5 | 7.5 | 220 | 0~250 | 30 | 1 |
| TDGC2-10 | 10 | 220 | 0~250 | 40 | 1 |
| TDGC2-15 | 15 | 220 | 0~250 | 60 | 1 |
