25A 3POLE MOTOR PROTECTION CIRCUIT BREAKER
Model: 3VU13-1MP00
Providing motor short-circuit protection on the category of AC3 IEC60947. Protection and control of Single-phase or 3-phase motors.
Isolation and breaking Function.
Short-Circuit protection.
Power Switching.
Non-Reversing.
MPCB are designe for connecion by screw clamp terminals. It can be supplied with lugs or
spring terminal connections. Resistant to harsh environment, vibration and impact and are
even more effective when conductors without cable ends are used. Each connection can
take two independent conductors.
Operation:
Control is manual and local when the motor circuit-breaker is used on its own. Control is
automatic and remote when it is associated with a contactor.
Pushbutton control:
Energisation is controlled manually by operating the Start button "I".
De-energisation is controlled manually by operating the Stop button "O", or automatically by
the thermal-magnetic protection elements or by a voltage trip attachment.
The motor circuit-breakers are easily installed in any configuration thanks to their universal
fixing arrangement: screw fixing or clip-on mounting on symmetrical, asymmetrical or
combination rails.
Utilisation Category: AC3, Conforming to IEC60947-4-1.
Shock Resistance: Conforming to IEC60068-2-27.
Vibration Resistance: Conforming to IEC60068-2-6.
Flame Resistance: Conforming to IEC60695-2-1.
Suitable for Isolation: Conforming to IEC60947-1 & 7-1-6.
Sensitivity to phase failure: Yes, Conforming to IEC60947-4-1 & 7-2-1-5-2.
- Rated Current.............................................................25A
- Frame Current.............................................................25A
- No. of Pole...................................................................3-POLE
- Rated Operational Voltage.........................................690VAC
- Rated Insulated Voltage.............................................690VAC
- Frequency....................................................................50/60Hz
- Standards................................................IEC60947-1,IEC60947-2,IEC60947-4-1
- IP / NEMA Rating.........................................................IP20
- Connection..................................................................Screw+Cable Lug
- Working Temperature................................................-20℃~+80℃
- Mechanical Life.......................................................... 20,000 times
- Sample Service...........................................................Pay to Provide
- Quality Assurance......................................................24 months
| Item |
Rated Current |
Thermal Release | Instantaneous Release |
Recommended Motor Rating 415V |
Case Qty. | |
| Model | (A) | (A) | (A) | KW | HP | (Pcs) |
| 3VU13-1MB00 | 0.16 | 0.1-0.16 | 1.9 | - | - | 50 |
| 3VU13-1MC00 | 0.24 | 0.16-0.24 | 2.9 | 0.06 | - | 50 |
| 3VU13-1MD00 | 0.4 | 0.24-0.4 | 4.8 | 0.09 | 0.12 | 50 |
| 3VU13-1ME00 | 0.6 | 0.4-0.6 | 7.2 | 0.12 | 0.18 | 50 |
| 3VU13-1MF00 | 1 | 0.6-1 | 12 | 0.25 | - | 50 |
| 3VU13-1MG00 | 1.6 | 1-1.6 | 19 | 0.37 | 0.55 | 50 |
| 3VU13-1MH00 | 2.4 | 1.6-2.4 | 29 | 0.75 | - | 50 |
| 3VU13-1NH00 | 3.2 | 2-3.2 | 38 | 1.1 | - | 50 |
| 3VU13-1MJ00 | 4 | 2.4-4 | 48 | 1.1 | - | 50 |
| 3VU13-1NJ00 | 5 | 3.2-5 | 60 | 1.5 | 1.5 | 50 |
| 3VU13-1MK00 | 6 | 4-6 | 72 | 2.2 | 2.2 | 50 |
| 3VU13-1NK00 | 8 | 5-8 | 96 | 3 | - | 50 |
| 3VU13-1ML00 | 10 | 6-10 | 120 | 3 | 4 | 50 |
| 3VU13-1NL00 | 13 | 8-13 | 156 | 4 | 5.5 | 50 |
| 3VU13-1MM00 | 16 | 10-16 | 190 | 7.5 | - | 50 |
| 3VU13-1MN00 | 20 | 14-20 | 240 | 7.5 | - | 50 |
| 3VU13-1MP00 | 25 | 18-25 | 300 | 11 | - | 50 |
