Building material use brick/cement compression testing machine 30 ton
Application
YES-300 digital display compression testing machine mainly used for concrete rupture strength
testing,cement,plastic sand,and red brick building materials compression resist testing. Widely used in metallurgy,building materials,space flight and aviation,colleges and universities,R and D institution lines.The test operation and data processing meets standard requirements.
Main technical specifications:
Maximum capacity: 300kN
Force range: 12-300 kN
Accuracy : ±1%
Distance between up and down compression plate:250mm
Test space width: 280mm
Size of up plate: 125mm
Size of down plate: 175×175mm
Piston scale: 120mm
Power supply: 3-phase 380V±10%, 50Hz
Work environment: 10-30℃, relative humidity is less than 80%
Dimension: 950×650×1450(mm)
Weight: 700 kg
Main configuration:
One main machine
high-precision load cell
high-precision data acquisition system
Oil source: one
Hydraulic control valve: one
Main features:
Main machine
The main machine has two columns.
Manual control the load, easy and convenient to operate
Limit protection device, keep safe
Auto-load when the force is more than 2%-10% of full scale
Display system
The machine can display testing force, force peak, because it adopts advance data acquisition chip.
Follow the load ratio; it is much more even and accurate
It has data interface, can connect with internet and realize sharing the resources.
