BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry

BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry thumbnail-1
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry thumbnail-2
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry thumbnail-3
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry thumbnail-4
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry thumbnail-5
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry thumbnail-6
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry photo-1
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry photo-2
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry photo-3
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry photo-4
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry photo-5
BBZ DT100 Series Excellent Anti-interference Intelligent Industrial Temperature Instruments in Boilers Industry photo-6
US$ 50 - 220 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
BBZ
Model Number:
BBZ UTI6
Contact Supplier Request Quote Chat Now
Henan BBZ Automation Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Ningbo Lianyungang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name BBZ
Model Number BBZ UTI6
Product Description

BBZ DT100 series RS485 Excellent anti-interference Intelligent


industrial temperature instruments in boilers industry


Product Application

BBZ DT100 series Excellent anti-interference Intelligent industrial temperature instruments in boilers industry, assembled type integrated temperature transmitter is widely used in petroleum, chemical, power generation, pharmaceuticals, textiles and boilers industry.

Specifications

Accuracy
0.5% FS, 0.25% FS, 0.2% FS
Output
thermal resistance, thermocouple, 4 ~ 20 mA, 0 to 5 V
Working voltage
12 V ~ 32 V
Allowable load resistance
500 Ω (24 VDC power supply)
Ambient temperature
- 25 ~ 80 ℃
Ambient humidity
5% ~ 95%
Mechanical vibration
f≤50Hz, amplitude ≤0.15mm
Category
Material
Graduation
Measuring range
Thermocouple
Nickel chrome - constantan
E
0 ~ 1000 ℃
Nickel chrome - nickel silicon
K
0 ~ 1300 ℃
Platinum rhodium 10 - platinum
S
0 ~ 1600 ℃
Platinum rhodium 30 - platinum rhodium 6
B
0 ~ 1800 ℃
Copper-constantan
T
0 ~ 400 ℃
Thermal resistance
Iron - constantan
J
: 0 ~ 1200 ℃
Copper thermal resistance
Cu50
- 50 ~ 150 ℃
Copper thermal resistance
Cu100
- 50 ~ 150 ℃
platinum thermal resistance
Pt100
- 200 ~ 600 ℃

Features

1. Digital multi-point calibration and using a dedicated chip to greatly improve the accuracy and stability

2. RS485 fieldbus

3. LCD display, adjustable unit

4. On-site zero calibration function

5. Adjustable damping time to ensure the long-term stability

6. Excellent anti-interference

7. Overvoltage/ overcurrent protection, reverse polarity protection

8. Explosion-proof function

Description

BBZ DT100 series intelligent industrial temperature transmitter, assembled type integrated temperature transmitter can support the use of regulators display device, control system, recorder, etc.

Applications
