BBZ UTI7 Wireless Digital Temperature for Data Communication and Gathering in Poor Weather Condition

BBZ UTI7 Wireless Digital Temperature for Data Communication and Gathering in Poor Weather Condition photo-1
BBZ UTI7 Wireless Digital Temperature for Data Communication and Gathering in Poor Weather Condition photo-2
BBZ UTI7 Wireless Digital Temperature for Data Communication and Gathering in Poor Weather Condition photo-3
BBZ UTI7 Wireless Digital Temperature for Data Communication and Gathering in Poor Weather Condition photo-4
BBZ UTI7 Wireless Digital Temperature for Data Communication and Gathering in Poor Weather Condition photo-5
BBZ UTI7 Wireless Digital Temperature for Data Communication and Gathering in Poor Weather Condition photo-6
US$ 200 - 450 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
BBZ
Model Number:
BBZ UTI7
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Ningbo Lianyungang
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin China
Brand Name BBZ
Model Number BBZ UTI7
Product Description

BBZ UTI7 Wireless Digital Temperature for data communication and


gathering in poor weather condition environment


Product Application

BBZ UTI7 Wireless Digital Temperature for data communication and gathering in poor weather condition environment is specially suitable for the temperature measurement in open country or the scene, where is unable to provide power source, but need data to carry on live transmission, such as oil field, oil well, heating pipelines and so on.

Specifications

Measuring medium
gas or liquids compatible to stainless steel
Temperature range
Thermocouple: E:0~750℃;K:0~1200℃;S:0~1300; B:0~1600℃
Thermoresistor: PT100:- 200 ~500℃

Insert depth
50mm~2500mm(as customer's request)
Accuracy
0.25%FS, 0.5%FS
Output signal
wireless communication
Operating frequency
430~470MHz
Transmitting distance
200m or 800m
Long-term stability
<0.15%FS/year
Supply voltage
3.6V high performance lithium battery
Insulation resistance
100MΩ@50VDC
Operating temperature range
-30~60℃
Display
dynamic 4 digit LCD digital indicator in MPa,KPa unit
Temperature coefficient of zero
0.2%FS/10℃
Temperature coefficient of span
0.2%FS/10℃
Process connection
M20 ×1.5 (male) or others
Electrical connection
M20 × 1.5 (female )
Material of wetted part
1Cr18Ni9Ti
Material of housing
cast aluminium
Explosive-proof rate
ExiaIIBT4,ExdIIBT4

Features


1. Wireless transmission, not need any field wiring

2. Use large capacity and high performance lithium battery as power supply, not need external power supply

3. Sensor quantity possible to expand willfully in a scope, the adjustment is more convenient

4. High gathering precision, stable transmission, very little network maintenance

5. Anti-radar and explosive-proof design, suitable for data communication and gathering in poor weather condition environment

Description

BBZ UTI7 Wireless Digital Temperature for data communication and gathering in poor weather condition environment is constructed by temperature element, signal processing electric circuit, central processor and wireless communication circuit.

This product uses the large capacity high performance lithium battery as power supply, its service life is 1~2 years, does not need any other external power source.

BBZ UTI7 Wireless Digital Temperature for data communication and gathering in poor weather condition environment realize long-distance realtime monitoring and wireless data transmission without any field wiring, not only save manpower, and also save construction costs.
