Bulletproof Astm Jis gb High Quality Steel Plate Low Price

Bulletproof Astm Jis gb High Quality Steel Plate Low Price thumbnail-1
Bulletproof Astm Jis gb High Quality Steel Plate Low Price thumbnail-2
Bulletproof Astm Jis gb High Quality Steel Plate Low Price thumbnail-3
Bulletproof Astm Jis gb High Quality Steel Plate Low Price thumbnail-4
Bulletproof Astm Jis gb High Quality Steel Plate Low Price thumbnail-5
Bulletproof Astm Jis gb High Quality Steel Plate Low Price thumbnail-6
Bulletproof Astm Jis gb High Quality Steel Plate Low Price photo-1
Bulletproof Astm Jis gb High Quality Steel Plate Low Price photo-2
Bulletproof Astm Jis gb High Quality Steel Plate Low Price photo-3
Bulletproof Astm Jis gb High Quality Steel Plate Low Price photo-4
Bulletproof Astm Jis gb High Quality Steel Plate Low Price photo-5
Bulletproof Astm Jis gb High Quality Steel Plate Low Price photo-6
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
CUP-ET
Model Number:
cupet-bulletproof steel
Contact Supplier Request Quote Chat Now
Beijing CUP-ET Science&Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name CUP-ET
Model Number cupet-bulletproof steel

bulletproof astm jis gb high quality steel plate low price



Product Specification

product protection level bullet Weight(g) Muzzle velocity m/sec test Range (m)  Thickness(mm) weapon &Ammunition
bulletproof steel ENB4 ,NIJIIIA   15.6   495±10 5 2.8 0.44 Magnum
ENB5,NIJIII 4 950±10 5 6.3 Rifle M16 A2 ,5.56x45 (ssl09)
BR/FB6 ,NIJLevel III 9.5 830±10 5 6.3 Rifle M16 A2, FN FAL, 7.62x51
NIJIII- 8 720±10 10 4.4 AK47 7.62x39,MSC bullet
BR/FB6 ,NIJLevel III 9.7  838±10 10 6.3 M14,M80   7.62x51mm
NIJ III + 3.56 830±10 10 9 M16 A2 5.56x45 (M193)



Ballistic steel plate technical paremeters

applications Armored vehicle, bulletproof vest and helmet, armored equipments
chemical C Si Mn P S Cr Nl Mo Ceq
compositions ≤0.32 ≤1.8 ≤1.1 ≤0.015 ≤0.008 ≤1.5 ≤1.8 ≤0.5 ≤0.70
(wt%) Ceq-carbon equivalent, Ceq=C+Si/24+Mn/6+Ni/40+Cr/5+Mo/4+V/14
Mechanical Properties

Tensile strength(Rm, Mpa)

≥1650 		Yield strength (Rp0.2, Mpa)      ≥1400

Elongation (A,%) ≥8%
Impact properties AKV2 (-400C)≥20J (10mmx10mmx55mm test specimen)
  *-Average of three specimens, transverse to rolling direction
Hardness range 480-530HB

Testing

 Brinell hardness test EN ISO 6506-1 Each heat treatment individual
Tensile test EN 10002-1
Charpy impact test EN 10045-1 t>10mm
Delivery condition Quenched and tempered as EN10025-6



bulletproof astm jis gb high quality steel plate low price

Once you book the order, you can come to our factory sampling from each lot to do the field shooting test in testing lab and get the certificate. All the process can be done in our factory. Only we could promise and do it in China. Of course, we also welcome you to visit our factory before you make your decision.



USA Standard NIJ 0101.06

Armor Type

Test Round

Test Ammunition

Nominal Bullet Mass

Minimum Required Bullet Velocity

No.of Shots

No.of Test

II-A

1

9mm

FMJ

8.0g

124gr

373m/s

(1225ft/s)

6

4

2

40S&W

FMJ

11.7g

180gr

325m/s

(1155ft/s)

6

4

II

1

9mm

FMJ

8.0g

124gr

398m/s

(1305ft/s)

6

4

2

357Magnum

JSP

10.2g

158gr

436m/s

(1430ft/s)

6

4

III-A

1

.357SIG

FMJFN

8.1g

125gr

448m/s

(1470ft/s)

6

4

2

44Magnum

SJHP

15.6g

240gr

436m/s

(1430ft/s)

6

4

III

1

7.62mm

NATO FMJ

9.6g

147gr

847m/s

(2780ft/s)

6

2

IV

1

.30Caliber

M2AP

10.8g

166gr

878m/s

(2880ft/s)

1

2

bulletproof astm jis gb high quality steel plate low price

bulletproof astm jis gb high quality steel plate low price

bulletproof astm jis gb high quality steel plate low price

bulletproof astm jis gb high quality steel plate low price

bulletproof astm jis gb high quality steel plate low price

bulletproof astm jis gb high quality steel plate low price



bulletproof astm jis gb high quality steel plate low price

1.Q:How about the quality of your bulletproof products?

   A:Quality is vital to our order;our products are made by top-shelf meterial.And we have simple-assigned person following up the orders from the beginning to the end.

2.Q:Is OEM or ODM ok to your company?

   A:Yes.Our company can do OEM or ODM for the customer from all the world.

3.Q:Are you a factory or trading company?

   A:Yes, we are. we are a factory independentlyto produce a series of bullet-proof products.

4.Q:Can you offer us some sample before comfirming the order?

   A:Of course,we are willing to do that.
