Help Center1000L Stainless Steel Bright Tank With Cooled Jacket for Beer Maturing and Serving
Related Products
-
10BBL Bright Tank for Beer Maturing and ServingUS$ 1,550 - 8,000MOQ: 1 Set -
300L Bright Tank for Beer Maturing and ServingUS$ 1,550 - 8,000MOQ: 1 Set
-
100L-10000L Bright Tank for Beer Maturing and ServingUS$ 1,550 - 8,000MOQ: 1 Set
-
Automatic Stainless Steel Beer Bright Tank for Brewery Hot SellUS$ 40,000 - 60,000MOQ: 1 Set
-
Commercial Beer Brewery Equipment for Sale Stainless Steel Bright Beer TankUS$ 40,000 - 60,000MOQ: 1 Set
SUS304 bright beer tank for beer maturing and serving
&Bright beer tank Descriptions&
Bright beer tanks are often also called serving tanks, tax determination tanks or clear beer tanks (=CBTs), bright beer tanks (=BBTs) or maturation or conditioning tanks. These tanks are used for the storage of the beer prior to being served or packaged. Depending on their application the beer serving tanks can be glycol jacketed or can be located in a cold room.For brewpubs serving is often done by pumping or pressurizing the beer toward the serving location.
&The specification of bright beer tank&
#Design pressure 45 psi (3bar); working pressure 15psi (1bar)
#4 stainless steel legs with leveling footpads
#Interior shell: 304 stainless steel, thickness 3mm
#Exterior shell: 304 stainless steel, thickness 2mm
#Flanged and dished head top and bottom
#20% headspace unless a different volume is requested
#Combined drain extensions and beer port are standard
#Top manway or side manway door
#Dual zone in sidewall and bottom dimple cooling jacket with glycol inlet and outlet
#Polyurethane insulation thickness 80mm for cooling jacket on side and bottom
#Non welding CIP arm and rotating 360 degree reach spray ball
#Carbonation system with micron stone
#Solenoid valve, pressure relief valve (safe valve) are standard.
#Pressure gauge
#Temperature sensor well
#All clamps and gaskets to attach all accessories
#Tank complete with piping, fittings, sanitary valves and all parts.
#If you are would like to change, add, remove or modify any part of the tanks, we can accommodate that. Specific fitting sizes,
changes and locations will be set during the design process after a deposit is taken.
Bright Tank Series |
Volume by US Gallon |
Conical Degree |
Diameter |
Height |
10HL Bright Tank |
159US Gallon |
60 (70,90 availabe) |
1260mm |
2100mm |
20H Bright Tank |
317US Gallon |
60 (70,90 availabe) |
1560mm |
2350mm |
&The accessories&
| Bright Beer Tank Accessories | ||||
| 1 | CIP Arm | SUS304/Φ32/butterfly valve | 1pcs | |
| 2 | Pipe Support | SUS304 | 3pcs | |
| 3 | Spray Ball | SUS304/Φ25 | 1pcs | |
| 4 | Pressure Gauge | Shockproof/Mpa&PSI | 1pcs | |
| 5 | Discharge Arm | SUS304/with butterfly valve | 1pcs | |
| 6 | Pressure Relief Valve | SUS304/2bar | 1pcs | |
| 7 | Sanitary Sample Valve | SUS304 | 1pcs | |
| 8 | Carbonation Stone | with butterfly valve | 1pcs | |
| 9 | Level Tube | with SUS ball valve | 1pcs | |
| 10 | Foot Pad | SUS304 | 4pcs | |
| 11 | Butterfly Valve | SUS304 | As designed | |
| 12 | Tri clamp | SUS304 | As designed | |
| 13 | Gaskets | Rubber | As designed | |
