Stainless steel insulated 1000L brewery fermentation tank
The micro beer femrneters are also called CCT’s (Cylindrical Conical Tanks), FV’s (Fermentation
Vessel), primary fermentor or unitanks as they are used both for fermenting and lagering. Fermenting is
the process during which the yeast transforms the wort into beer. Lagerings takes place after fermenting
and is the time given to the beer to stabilize and age after fermenting.
Introductio of the beer fermenters tanks
Our brewery fermentation tanks can be individually temperature controlled through glycol jackets and
are mostly equipped with accessories such as overpressure and under pressure valve, CIP cleaning jet,
sanitary sample valve, manhole,etc. The design of TBE fermenters is based on our vast beer knowledge
and especially the conical fermenter bottom and the fact that we combine fermentation and maturation in
the same vessel is very important.
Detailed showing of the fermentation tanks
Most breweries today use cylindro-conical vessels, or CCVs, which have a conical bottom and a cylindrical
top. The cone's aperture is typically around 60°, an angle that will allow the yeast to flow towards the
cone's apex, but is not so steep as to take up too much vertical space. CCVs can handle both fermenting
and conditioning in the same tank. At the end of fermentation, the yeast and other solids which have fallen
to the cone's apex can be simply flushed out of a port at the apex.
Fermentation Tank Series |
Volume in US Gallon |
Diameter |
Height |
1HL Fermentation Tank |
26US Gallon |
620mm |
1600mm |
2HL Fermentation Tank |
53US Gallon |
820mm |
1800mm |
3HL Fermentation Tank |
79US Gallon |
960mm |
1900mm |
4HL Fermentation Tank |
106US Gallon |
960mm |
2100mm |
5HL Fermentation Tank |
132US Gallon |
1010mm |
2100mm |
6HL Fermentation Tank |
159US Gallon |
1060mm |
2150mm |
8HL Fermentation Tank |
211US Gallon |
1060mm |
2550mm |
10HL Fermentation Tank |
264US Gallon |
1210mm |
2550mm |
12HL Fermentation Tank |
317US Gallon |
1360mm |
2550mm |
15HL Fermentation Tank |
396US Gallon |
1560mm |
2620mm |
20HL Fermentation Tank |
528US Gallon |
1560mm |
3100mm |
25HL Fermentation Tank |
660US Gallon |
1560mm |
3450mm |
30HL Fermentation Tank |
793US Gallon |
1760mm |
3500mm |
4 stainless steel legs with leveling footpads
Interior shell: 304 stainless steel, thickness 3mm
Exterior shell: 304 stainless steel, thickness 2mm
Interior and exterior finish bright polish to 0.6~0.8, hygiene surface
60 degree cone bottom, other angles can be specified during the design process
Combined drain extensions and beer port in cone are standard
25% headspace, unless a different volume is requested
Top manway or side manway door
Dual zone in sidewall and cone dimple cooling jacket with glycol inlet and outlet
Polyurethane insulation thickness 80mm for cooling jacket on side and bottom
Fully welded exterior shell
Non welding CIP arm and rotating 360 degree reach spray ball
Solenoidrelief valve, pressure relief valve (safe valve) are standard
Pressure gauge
You can click the photos directly to learn more details of these brewery equipment.
- you can enjoy our free consultation service any time
- you can let us help you plan and design your brewery project if you don't know how to do it quite well
- you will be free of charge for our debugging the brewery equipment to get it work perfectly
- you can decide that which port the goods will arrive at
- you will be trained how to maintain and operate the brew system personally if you are not good at it
- you will learn some new beer production techniques from our professional brewer
- you will have our words:
- Provide 36 months complete warrantee for main parts and life-time maintenance service;
- The seller is responsible for the nature damage of the machinery in the
- warranty period except for man-made damage.
7BBL beer brewing equipment for sale
20BBL stainless steel beer brewery system price
Welcome to send us inquiry for detailed cost of the 1000L brewery fermentation tank!
