Insulated 6000L cone cylindrical industrial beer fermenter
Introduction of the beer fermenters
Fermenters are also called CCT’s (Cylindrical Conical Tanks), FV’s (Fermentation Vessel), primary fermentor
unitanks as they are used both for fermenting and lagering. Fermenting is the process during which the yeast
transforms the wort into beer. Lagerings takes place after fermenting and is the time given to the beer to
stabilize and age after fermenting.
Our industrial beer fermenters can be individually temperature controlled through glycol jackets and are
mostly equipped with accessories such as overpressure and under pressure valve, CIP cleaning jet, sanitary
sample valve, manhole,etc. The design of TBE fermenters is based on our vast beer knowledge and
especially the conical fermenter bottom and the fact that we combine fermentation and maturation in the
same vessel is very important. When calculating your fermenting and lagering capacity and configuration
sufficient time for fermenting and lagering to produce quality beers must be taken into consideration.
Basic specifications of our commercial beer fermenter tanks
Fermentation Tank Series |
Volume in US Gallon |
Diameter |
Height |
30HL Fermentation Tank |
793US Gallon |
1760mm |
3500mm |
35HL Fermentation Tank |
925US Gallon |
1760mm |
3750mm |
40HL Fermentation Tank |
1057US Gallon |
1760mm |
4050mm |
50HL Fermentation Tank |
1321US Gallon |
1760mm |
4540mm |
60HL Fermentation Tank |
1585US Gallon |
1960mm |
4700mm |
70HL Fermentation Tank |
1849US Gallon |
1960mm |
5200mm |
100HL Fermentation Tank |
2642US Gallon |
2250mm |
5700mm |
150HL Fermentation Tank |
3963US Gallon |
2250mm |
7550mm |
The 6000L commercial beer fermenter usually fits 3000L/6000 brewhouse.
It is suitable for commercial brewery..
It is suitable for the beer production of about 36000L-120000 per month.
Whole body adopts certificated SUS304. Every details are strictly processed and controlled.
* Interior shell: 304 stainless steel, thickness 3mm
* Exterior shell: 304 stainless steel, thickness 2mm
* Interior and exterior finish bright polish to 0.6~0.8, hygiene surface
* 60 degree cone bottom, other angles can be specified during the design process
* Combined drain extensions and beer port in cone are standard
* 25% headspace, unless a different volume is requested
* Top manway or side manway door
* Dual zone in sidewall and cone dimple cooling jacket with glycol inlet and outlet
* Polyurethane insulation thickness 80mm for cooling jacket on side and bottom
* Fully welded exterior shell
* Non welding CIP arm and rotating 360 degree reach spray ball
1.3 years warranty
2.Free installation and training
3.Design and maintenance for free
4.High quality and best price
5.inner and outer of the tanks have been mirror polish
6.the material can be stainless steel with low price or red copper with nice-looking
7.the capacity can be 50L~30,000L
Packaging : We consider all different potential situation in the delivery, so we use every prevention measures
to avoid any potential inconvenience or trouble
a.Bulk cargo: Standard wooden case which can avoid any clash during the sea or air transportation in case of
causing damage to the surface of our products.
b. Container cargo: the equipment will be bound firmly and won’t easily swing to the side, or up, or down.
Shipping: Deliver from Qingdao port within 30-45 days after the payment
1. you can enjoy our free consultation service any time
2. you can let us help you plan and design your brewery project if you don't know how to do it quite well
3. you will be free of charge for our debugging the brewery equipment to get it work perfectly
4. you can decide that which port the goods will arrive at
5. you will be trained how to maintain and operate the brew system personally if you are not good at it
6. you will learn some new beer production techniques from our professional brewer
7. you will have our words:
8. Provide 36 months complete warrant for main parts and life-time maintenance service;
9. The seller is responsible for the nature damage of the machinery in the
10. warranty period except for man-made damage.
11. All spare parts and wearing parts are attached with the machinery for free;
Our company is a professional beer equipment manufacturer. We are specialized in professional design,
manufacture, installation and commissioning of various beer equipments and supporting facilities.
Our products include mashing equipment, fermentation equipment, yeast spread cultivation equipment, and
refrigeration equipment for small and medium-sized brewery, hotel, pub and etc.
Other products you may interest:
Stainless steel beer brewhouse equipment
1000 Liter stainless steel beer brewhouse
Welcome to send us inquiry for detailed cost of the industrial beer fermenters!
