Help CenterRotary Tiller (LG) for Tractor
Related Products
Specifications
New Designed rotary cultivator with more compact structureDifferent sizes suitable for more horsepower tractor
MODEL |
LG-90 |
LG-100 |
LG-105 |
LG-125 |
DIMENSIONS(L*W*H) |
1100x800x700mm |
1200x800x700mm |
1250x800x700mm |
1450x800x700mm |
STRUCTURE WEIGHT |
250kg |
260kg |
265kg |
285kg |
TILLING WIDTH |
895mm |
995mm |
1045mm |
1245mm |
TILLING DEPTH |
120mm |
120mm |
120mm |
120mm |
WORKING EFFICIENCY |
1500-2500sq/h |
1700-2600sq/h |
1800-2600sq/h |
2000-2900sq/h |
PTO TURNNING SPEED |
540r/min |
540r/min |
540r/min |
540r/min |
PTO SPLINE |
6x8x700mm |
6x8x700mm |
6x8x700mm |
6x8x700mm |
POWER REQUIRED |
16-20hp |
18-22hp |
20-28hp |
25-30hp |
| ||||
MODEL |
LG-135 |
LG-150 |
LG-180 |
|
DIMENSIONS(L*W*H) |
1550x800x700mm |
1700x800x700mm |
2000x800x700mm |
|
STRUCTURE WEIGHT |
300kg |
320kg |
350kg |
|
TILLING WIDTH |
1345mm |
1495mm |
1795mm |
|
TILLING DEPTH |
120mm |
120mm |
120mm |
|
WORKING EFFICIENCY |
2000-3000sq/h |
2200-3000sq/h |
2200-3200sq/h |
|
PTO TURNNING SPEED |
540r/min |
540r/min |
540r/min |
|
PTO SPLINE |
6x8x700mm |
6x8x700mm |
6x8x700mm |
|
POWER REQUIRED |
25-30hp |
30-50hp |
40-75hp |
|
Send Inquiry to This Supplier
