Help CenterST1200 Steel Mesh Woven Rubber Conveyor Belt
Related Products
-
Steel Mesh Cord Conveyor Belt - STN1200NegotiableMOQ: 1 Roll -
High Efficiency With Good Quality Rubber Conveyor Belt for Mining IndustryNegotiableMOQ: 1 Roll
-
High Efficiency Rubber Conveyor Belt Used in Underground Mining WellsNegotiableMOQ: 1 Roll
-
Harbor Long Distance Conveying Steel Cord Rubber Conveyor BeltNegotiableMOQ: 1 Roll
-
High Quality St2000 Wire Mesh Cord Conveyor BeltNegotiableMOQ: 1 Roll
Special steel cord conveyor belt
Anti-tear steel cord conveyor belt for general use
Cold resistant steel cord conveyor belt
Steel cord Elevation conveyor belt
Standard belt specification
Item |
St 630 |
St 800 |
St 1000 |
St 1250 |
St 1600 |
St 2000 |
St 2500 |
St 3150 |
St 3500 |
St 4000 |
St 4500 |
St 5000 |
St 5400 |
|
Tensile Strength N/mm |
630 |
800 |
100 |
1250 |
1600 |
2000 |
2500 |
3150 |
3500 |
4000 |
4500 |
5000 |
5400 |
|
Max Cord Diam mm |
3.0 |
3.5 |
4.0 |
4.5 |
5.0 |
6.0 |
7.2 |
8.1 |
8.6 |
8.9 |
9.7 |
10.9 |
11.3 |
|
Cord pitch±1.5mm
|
10 |
10 |
12 |
12 |
12 |
12 |
15 |
15 |
15 |
16 |
16 |
17 |
17 |
|
Top Cover thickness mm
|
5 |
5 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8 |
8 |
8.5 |
9 |
Bottom cover thickness mm |
5 |
5 |
6 |
6 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8.5 |
9 |
Belt width Steel cord No. | |||||||||||||
800 |
75 |
75 |
63 |
63 |
63 |
63 |
50 |
50 |
50 |
|
|
|
|
1000 |
95 |
95 |
79 |
79 |
79 |
79 |
64 |
64 |
64 |
64 |
59 |
55 |
55 |
1200 |
113 |
113 |
94 |
94 |
94 |
94 |
76 |
76 |
77 |
77 |
71 |
66 |
66 |
1400 |
133 |
133 |
111 |
111 |
111 |
111 |
89 |
89 |
90 |
90 |
84 |
78 |
78 |
1600 |
151 |
151 |
126 |
126 |
126 |
126 |
101 |
101 |
104 |
104 |
96 |
90 |
90 |
1800 |
|
171 |
143 |
143 |
143 |
143 |
114 |
114 |
117 |
117 |
109 |
102 |
102 |
2000 |
|
|
159 |
159 |
159 |
159 |
128 |
128 |
130 |
130 |
121 |
113 |
113 |
2200 |
|
|
|
|
|
176 |
141 |
141 |
144 |
144 |
134 |
125 |
125 |
2400 |
|
|
|
|
|
193 |
155 |
155 |
157 |
157 |
146 |
137 |
137 |
2600 |
|
|
|
|
|
209 |
168 |
167 |
170 |
170 |
159 |
149 |
149 |
2800 |
|
|
|
|
|
|
|
|
194 |
194 |
171 |
161 |
161 |
GB/79770 Cover property and grade
Item |
Tensile Strength ≥MPa |
Change rate of elongation ≥% |
Abrasion ≤mm³ |
D |
18 |
400 |
90 |
H |
25 |
450 |
120 |
L |
20 |
400 |
150 |
P |
14 |
350 |
200 |
Note:D—under strong abrasion condition;H—under serious laceration condition ;L—under normal condition;P—for oil, hot, acid and alkali, coldness and flame resistant belt | |||
DIN2213 Cover property and grade
Grade |
Min Tensile strength MPa |
Change rate of elongation ≥% |
Abrasion ≤mm³ |
W |
18 |
400 |
90 |
X |
25 |
450 |
120 |
Y |
20 |
400 |
150 |
K* |
20 |
400 |
200 |
Note:*suit for DIN22103 fire resistant belt , and the cover rubber is up to the DIN22104 standard. | |||
We offer EP/Nylon/Cotton/Steel mesh belt with heat/cold/high temperature/burn/
chemical/oil resistant properties and our rubber belts are widely used in mining/
cements/metallurgy /ports industries.Any needs,please contact us.
Our website:
Tel:+86 0512-55371628
Mobile:+86 15962354789
Skype:selina-selina13
ZIP:215600
