CHINA Supplier ST1200 Wire Mesh Reinforced Steel Cord Rubber Belt Conveyor

Name: CHINA Supplier ST1200 Wire Mesh Reinforced Steel Cord Rubber Belt Conveyor
Brand: HuaShen
SKU: 113900489
Availability: InStock

US$ 20 - 50 MOQ: 100 Meters

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

HuaShen

Model Number:

ST630-ST5400

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name HuaShen

Model Number ST630-ST5400

Product Description

CHINA supplier ST1200 wire mesh reinforced steel cord rubber belt conveyor

Special steel cord conveyor belt

Anti-tear steel cord conveyor belt for general use

Cold resistant steel cord conveyor belt

Steel cord Elevation conveyor belt

Standard belt specification
Belt strength (st-NO.)	Max Cord diam (mm)	composition	Pitch (mm)	Standard working tension (N/mm)	standard cover Thickn esst₁t₂ (mm)	Belt weight(Kg/m₂)	Min.pulley diam(mm)	cord strength KN/piece
St-630	3.0	96×7+IWS	10	90	5×5	19.1	800	6.93
St-800	3.5	K6×7+IWS	10	110	5×5	20.6	800	8.8
St-1000	4.0	K6×7+IWS	12	140	6×6	24.7	800	13.2
St-1250	4.5	K6×7+IWS	12	175	6×6	25.4	800	16.5
St-1600	5.0	K6×19+IWS	12	225	6×6	26.0	1000	21.12
St-2000	6.0	K6×19+IWS	12	285	8×6	30.0	1000	26.4
St-2500	7.2	K6×19W+IWS	15	355	8×6	32.2	1250	41.25
St-3150	8.1	K6×19W+IWS	15	450	8×8	35.7	1400	51.98
St-3500	8.6	K6×19W+IWS	15	500	8×8	44.9	1500	57.7
St-4000	8.9	K6×19W+IWS	15	570	8×8	46.6	1600	66
St-4500	9.7	K6×19W+IWS	16	645	8×8	49	1800	79.2
St-5000	10.9	K6×19W+IWS	17	715	8.5×8.5	53.6	1800	93.5
St-5400	11.3	K6×19W+IWS	17	760	9×9	57.5	2000	101

Horizontal Enhanced Steel Cord Rubber Conveyor Belt

Cover rubber property and grades

Test items		Property indexes
		GB9770-2001				DIN22131
		D D	H H	L L	P P	W W	X X	Y Y
Tensile strength	Mpa ≥	18	25	20	14	18	25	20
Pull to break the elongation rate	% ≥	400	450	400	350	400	450	400
after aging(707D) Change rate of tensile strength Change rate of elongation	%	-25+25	-25+25	-25+25	-25+25	-25+25	-25+25	-25+25
Abrasion	≤	90MM³	120MM³	150MM³	200MM³	90MM³	120MM³	150mm³

Adhesion of steel cord

GB/79770 Cover property and grade

Item	Tensile Strength ≥MPa	Change rate of elongation ≥%	Abrasion ≤mm³
D	18	400	90
H	25	450	120
L	20	400	150
P	14	350	200
Note:D—under strong abrasion condition;H—under serious laceration condition ;L—under normal condition;P—for oil, hot, acid and alkali, coldness and flame resistant belt

DIN2213 Cover property and grade

Grade	Min Tensile strength MPa	Change rate of elongation ≥%	Abrasion ≤mm³
W	18	400	90
X	25	450	120
Y	20	400	150
K*	20	400	200
Note:*suit for DIN22103 fire resistant belt , and the cover rubber is up to the DIN22104 standard.
