Heat resistant competitive price polyester fabric Ep800/5 cement conveyor belt for hot sinter ore
Our heat resistant conveyor belts have been developed and refined over many years so that they are more
than capable of meeting the demands of even the most extreme conditions, which in some cases can involve
temperatures as high as 400°C.
Industries where our heat resistant conveyor belts are used with great success include the cement industry,
recycling plants, the steel industry, foundries, the chemical industry and the petro-chemical industry.
The properties of heat resistant conveyor belt:
there are three types of conveyor belts available:
• T1 type - *temperature of material up to 150°C
• T2 type - *temperature of material up to 180°C
• T3 type - *temperature of material up to 220°C
Depends on the ambient temperature, grain size and contact duration
Short time peaks in temperature of material possible up to 400°C. For further details please contact us.
Specifications of heat resistant conveyor belt:
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Special Feature of Each Grade | ||
Grade |
Special Features |
Belt Surface Temperature |
HRT-1 |
HRT-1grade heat resistant belt is premium quality Styrene Butadiene
Rubber (SBR) compound with very good abrasion resistance
and heat resistance to handle hot materials up to 200ºC. This Grade
belt is highly resistant to variety of heat applications and good service
for iron ore, pellets, casting sand, coke and limestone etc.
|
100ºC~150ºC |
HRT-2 |
HRT-2 grade is IIR (butyl rubber) hot belt compound features excellent heat resistance which is designed to carry hot loads materials with non-cracking property. This belt is most suitable for the materials such as cement products, limestone, clay, slag, etc. |
150ºC~180ºC |
HRT-3 |
HRT-3 grade are the highest quality conveyor belt available to maximum heat resistance. Cover rubber is specially formulated ERP(ethylene propylene rubber)to provide extreme heat resistance and ply adhesion for the applications to handle hot cement, clinker, phosphate, hot sintered ore and hot chemical, fertilizer, etc. |
200ºC~220ºC |
Material Types and Belt Surface Temperatures | |||
Materials Carried |
Lump Size |
Temperature of Materials Carried |
Belt Surface Temperature |
Sintered Ore |
25~200mm
(1~8 inch)
|
*200~400ºC |
130~150ºC |
Return of Sintered Ore |
below 10mm
(0.4 inch)
|
260ºC |
150~190ºC |
Coke |
100~200mm
(4~8 inch)
|
70~100ºC |
50~60ºC |
Raw Material |
below 30mm
(1.2 inch)
|
180~220ºC |
100~120ºC |
Clinker |
10~30mm
(0.4~1.2 inch)
|
100~220ºC |
100~110ºC |
Cement |
Powder |
100~250ºC |
80~90ºC |
Metal Powder |
- |
170ºC |
120~130ºC |
Moldings |
- |
200~250ºC |
80~90ºC |
The physical and mechanical properties after heat resistant experiment can conform
to below requirements:
| Item | Model No. | ||||
| model.1 | model.2 | model.3 | model.4 | ||
| range of variation | |||||
| Hardness | The difference between before aging and after aging | 20 | ±20 | ±20 | |
| Max value after aging(IRHD) | 85 | ||||
| Tensile strength | lowest value after aging,Mpa | 12 | 10 | 5 | 5 |
| rate of property change reduces,%≤ | -25 | -30 | -40 | -40 | |
| elongation at break | rate of property change,%≤ | -50 | -55 | ||
| lowest value after aging,% | 200 | 180 | |||
Adhesion & Elongation of the heat resistant conveyor Belt:
Adhesion & Elongation of the Belt | |||||
|
belt carcass |
Adhension |
Elongation |
|||
|
Between Plies N/mm |
Between Rubber and Carcass |
Longitudinal %>= |
Longitudinal |
||
Rubber |
Rubber thickness |
||||
Cotton |
>=3.2 |
>=2.1 |
>=2.7 |
10 |
4 |
NN |
>=4.5 |
>=3.2 |
>=3.5 |
10 |
4 |
EP |
>=4.5 |
>=3.2 |
>=3.5 |
10 |
4 |
Heat resistant conveyor belts are suitable for:
• cement plants,concrete plants
• heating stations, cogeneration power plant,
• garbage incineration plants
• chemical industry,metallurgical industry
• steelworks, metal foundries, metal processing industry
| Application in Nonferrous Metal, Power, Machinery, Cement Industry | ||
| NO. | Clients | Products in Application |
| 1 | Huayuan Power Plant |
EP Belt, Ordinary Belt, Flame Resistant Belt |
| 2 | Junma Power Plant |
EP Belt, Ordinary Belt, Flame Resistant Belt |
| 3 | Guohua Taicang Power Co., Ltd. | EP Belt, Ordinary Belt |
| 4 | Jiangsu Huaiyin Huaneng Power Co., Ltd. | EP Belt, Ordinary Belt |
| 5 | Henan Zhoukou Longda Power Co., Ltd. |
Steel Cord Belt, EP Belt, Flame Resistant Belt |
| 6 |
Beijing Sanjili Power Group Co., Ltd. Zhangjiagang Branch |
EP Belt, NN Belt |
| 7 | Jiangxi Dexing Copper Mine |
EP Belt, Ordinary Belt, Flame Resistant Belt |
| 8 | Sichuan Lala Copper Mine | EP Belt, Ordinary Belt |
| 9 | Sichuan Huili Zinc Mine | EP Belt, Ordinary Belt |
| 10 | Heilongjiang Jixi Black Lead Mine |
Sidewall Belt, EP Belt,
Flame Resistant Belt |
| 11 | Pingxiang Conveyor Machinery Factory | NN Belt, Ordinary Belt |
| 12 | Hexing Conveyor Machinery Factory | EP Belt, Ordinary Belt |
| 13 | Yichun Conveyor Machinery Factory | NN Belt, Ordinary Belt |
| 14 | YongAn Cement Factory Ordinary Belt | Ordinary Belt |
| 15 | Jiangyin No.2 Cement Factory |
Heat Resistant Belt, Ordinary Belt, Sidewall Belt |
| 16 | Hangzhou Glass Factory | Ordinary Belt, Sidewall Belt |
Why choose us :
1.We are manufacturer,so the quality and price are directly controlled by ourself.
2.We owned the latest equipments and our engineers and production managers have more than 10years
experience.ODM and OEM are all available! what you expect is precisely what we want.
3.Our products have abtained patents,and there're more applying.
4.Our company has built cooperation relationship with many mine and metallury plants ,and their praise
proves our quality.
We offer EP/Nylon/Cotton/Steel mesh belt with heat/cold/high temperature/burn/
chemical/oil resistant properties and our rubber belts are widely used in mining/
cements/metallurgy /ports industries.Any needs,please contact us.
