Specifications
5V 3A g9 to gu10 lamp adapter1 Two-year warranty.
2 Certifications ROHS / UL/ SAA/ CSA/ BEAB/ PSE/ GS/ CE/ CB/ FCC /BSMI
5V 3A g9 to gu10 lamp adapter
Electric performance
l Output power 15W
Output vlotage:5V
Output current: 3A
l Input voltage 100~240V
l Input current 0.36A
l Input frequency 47-63Hz
l Depletion <0.3W min
l Efficiency 82%
Description
l Output 15W
l All range voltage input
l High efficiency , low loss .
l Meet “European commission of energy”
l Built in EMC/EMI filter
l You can choose the output voltage/current arbitrarily.
l Mainly used in APPLE, BENQ, SONY, TOSHIBA, MITAC, LENOVO, IBM, FUJITSU, HP, DELL, ASUS, ACER, SAMSUNG
Environmental and reliability
l Oprating temperature 0~40°C
l Oprating humidity 10~90%RH
l Storage temperature -20~+80°C
l Storage humidity 5~90%RH
l Leakage current 0.25mA max
l Withstanding voltage 3000Vac 1 minute 10mA max
l Burn-in 100% full load,40±5°C,4Hrs min
l MTBF meet MIL-HDBK-217F over 50k hours, full load 25°C
l Insulation resistance 500Vdc 100MΩmin between AC plug and DC plug and case.
Output voltage and current
Input condition |
Type |
Output votage(v) |
Output current(v) |
Noise |
Load regulation |
Line regulation
|
Output votage precision |
|
Input votage: 90~264
Input frequency 47~63Hz |
FYxxxyyyy |
3.0v-12.0v |
0A-10Amax |
100mv |
<5% |
<1% |
±5% |
FYxxxyyyy |
12.1v-13.5v |
0A-9Amax |
100mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
13.6v-15v |
0A-8Amax |
100mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
15.1v-18.0v |
0A-7Amax |
100mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
18.1v-19v |
0A-6.5Amax |
120mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
19.1v-20v |
0A-6Amax |
120mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
20.1v-220v |
0A-5.5Amax |
200mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
22.1v-24.0v |
0A-5Amax |
200mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
24.1v-26.5v |
0A-4.5Amax |
200mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
26.6v-30.0v |
0A-4Amax |
200mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
30.1v-34.0v |
0A-3.5Amax |
200mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
34.1v-40v |
0A-3Amax |
200mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
40.1-48v |
0A-2.5Amax |
200mv |
<5% |
<1% |
±5% |
|
FYxxxyyyy |
48.1-60v |
0A-2Amax |
200mv |
<5% |
<1% |
±5% |
