5v 1a Adapter Usb to Scart

FOB Price

US$ 1 - 2 / Piece

100 Pieces(Min. Order)

Port Shenzhen
Payment TermsMoney Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	HF_FYD
Model Number	FY0501000		Usage	Laptop

Product Description

Specifications

5v 1a adapter usb to scart
1)Two-year warranty.
2)ROHS/UL/SAA/ PSE/GS/ CE/CB/ FCC
3)8 years factory experience
4)OEM

5v 1a adapter usb to scart

Electric performance

Output voltage:5v

Output current: 1A

l Input voltage 100~240V

l Input current 0.36A

l Input frequency 47-63Hz

l Depletion <0.3W min

l Efficiency 82%

Description

l Output 5W

l All range voltage input

l High efficiency , low loss .

l Meet “European commission of energy”

l Built in EMC/EMI filter

l You can choose the output voltage/current arbitrarily.

l Mainly used in APPLE, BENQ, SONY, TOSHIBA, MITAC, LENOVO, IBM, FUJITSU, HP, DELL, ASUS, ACER, SAMSUNG

Environmental and reliability

l Oprating temperature 0~40°C

l Oprating humidity 10~90%RH

l Storage temperature -20~+80°C

l Storage humidity 5~90%RH

l Leakage current 0.25mA max

l Withstanding voltage 3000Vac 1 minute 10mA max

l Burn-in 100% full load,40±5°C,4Hrs min

l MTBF meet MIL-HDBK-217F over 50k hours, full load 25°C

l Insulation resistance 500Vdc 100MΩmin between AC plug and DC plug and case.

Output voltage and current

Input condition	Type	Output votage(v)	Output current(v)	Noise	Load regulation	Line regulation	Output votage precision
Input votage: 90~264 Input frequency 47~63Hz	FYxxxyyyy	3.0v-12.0v	0A-10Amax	100mv	<5%	<1%	±5%
	FYxxxyyyy	12.1v-13.5v	0A-9Amax	100mv	<5%	<1%	±5%
	FYxxxyyyy	13.6v-15v	0A-8Amax	100mv	<5%	<1%	±5%
	FYxxxyyyy	15.1v-18.0v	0A-7Amax	100mv	<5%	<1%	±5%
	FYxxxyyyy	18.1v-19v	0A-6.5Amax	120mv	<5%	<1%	±5%
	FYxxxyyyy	19.1v-20v	0A-6Amax	120mv	<5%	<1%	±5%
	FYxxxyyyy	20.1v-220v	0A-5.5Amax	200mv	<5%	<1%	±5%
	FYxxxyyyy	22.1v-24.0v	0A-5Amax	200mv	<5%	<1%	±5%
	FYxxxyyyy	24.1v-26.5v	0A-4.5Amax	200mv	<5%	<1%	±5%
	FYxxxyyyy	26.6v-30.0v	0A-4Amax	200mv	<5%	<1%	±5%
	FYxxxyyyy	30.1v-34.0v	0A-3.5Amax	200mv	<5%	<1%	±5%
	FYxxxyyyy	34.1v-40v	0A-3Amax	200mv	<5%	<1%	±5%
	FYxxxyyyy	40.1-48v	0A-2.5Amax	200mv	<5%	<1%	±5%
	FYxxxyyyy	48.1-60v	0A-2Amax	200mv	<5%	<1%	±5%
