Conical Twin Screw Barrel for Double Screw Extruder
US$ 1,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
QunYing
Model Number:
QY-CS-0008
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Conical Twin Extruder Screw & Twin Screw Extruder Screw DesignUS$ 1 - 10,000MOQ: 1 Set -
SACM645 Conical Twin Extruder Screw & Twin Screw Extruder Screw DesignUS$ 1 - 10,000MOQ: 1 Set
-
SACM645 Conical Twin Extruder ScrewUS$ 1 - 10,000MOQ: 1 Set
-
AISI 4140 Twin Conical Screw And BarrelUS$ 1 - 10,000MOQ: 1 Set
-
AISI 4140 Twin Conical Screw Barrel for PelletingUS$ 1 - 10,000MOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
QunYing
Model Number
QY-CS-0008
Specifications
1.Gurantee:2-4 years2.Certificates:GBT 19001-2008/ISO9001:2008/SGS
3.Base material 38CrMoALA
4.long operating life
Bimetallic Conical twin screw barrel for double screw extruder
The Specification of Conical twin screw and barrel
The Specification of Conical twin screw and barrel
|
Specification
(d/D)
|
Work Length
(mm)
|
Extruding Ability
KG/H)
|
Screw Speed
(rmp)
|
Φ25/Φ53 |
540 |
25-40 |
5-50 |
Φ35/Ø77 |
810 |
40-70 |
5-50 |
Φ45/Φ90 |
990 |
50-80 |
5-45 |
Φ50/105 |
1070 |
100-150 |
4-45 |
Φ51/105 |
1220 |
100-150 |
4-40 |
Φ55/Φ110 |
1220 |
120-180 |
4-40 |
Φ60/Φ125 |
1320 |
150-200 |
4-40 |
Φ65/Φ120 |
1440 |
200-250 |
4-40 |
Φ65/Φ132 |
1440 |
200-250 |
4-40 |
Φ70/Φ140 |
1460 |
250-320 |
4-35 |
Φ75/Φ150 |
1480 |
300-360 |
4-35 |
Φ80/Φ143 |
1800 |
300-360 |
4-35 |
Φ80/Φ156 |
1660 |
300-360 |
4-35 |
Φ90/Φ184 |
2000 |
400-500 |
3-35 |
Technical Date
Material |
38 38CrMoALA,SKD61,D2 etc. |
Hardness After Hardening&Tempering |
HB260-290 |
Depth of Nitrided |
0.5-0.8mm |
Hardness of The Surface |
Hv950-1100 |
Surface Roughness |
Ra0.4um |
Linearity of Screw |
0.015mm/m |
Conical twin screw barrel for double screw extruder machine
customer check the process of conical twin screw barrel producing
