Application of round rake
1.As a tedder: it can spread and flip the green-cut materials and withdraws, for drying evenly.
1). Spread, swath or windrow so crops dry down faster,
2). Tailor your tedding operations to a variety of crops and conditions by varying PTO speed or tine position,
3). Fixed-tine position provides aggressive tedding and is ideal for use in fresh-cut material or crops where leaf and
shatter losses are not a concern
4).Cam-operated tine position allows the tine bar rollers to follow the cam track to lift and release crop gently and
save valuable leaves
2.As a rake: it can collect teh dried materials into lines fro balers to pick up and pack them.
1). Precise raking action produces fluffy, uniform windrows that dry evenly
2). Self-centering wheels provide extral maneuverability by allowing you to make sharp turns and back up easily
without lifting the machine.
Features of round rake
1..Strong, rugged frame provides years of dependable performance.
2.Rotor tilt can be adjusted easily with a convenient crank for maximum crop handling.
3.Torque limiting clutch on the heavy-duty PTO provides overload protection. PTO speed is variable, so you can match ground speed to crop and field conditions.
4.Three wheel-height position let you adjust for different crops, conditions and operations.
5.Vertical tines pick up fewer stones and less debris than horizontal tines for cleaner tedding and raking.
6.Cam track adjustment allows you to quickly tailor tedding/raking action to varying crops and conditions without tools.
7.Convenient jack simplifies three-point hitch arrangements.
8.one machine, three functions, tedding, raking, and reversing multi-functions
Specification of round rake
Model |
HT2500 |
HT3500 |
HT400 |
Tedding width |
250cm |
350cm |
400cm |
Dimension |
2100x2500x950mm |
3100*3500*1000mm |
4010x3539x1196mm |
Weight |
160kg |
200kg |
290kg |
Tines of per rotors |
4 |
6 |
6 |
No of rotors |
6 |
8 |
8 |
Working speed |
4-8km/h |
4-8km/h |
4-8km/h |
Matched power |
18-50hp |
20-80hp |
35-80hp |
PTO RPM |
540r/m |
540r/m |
540r/m |
Package of round rake
Shipping by sea.
Our service of round rake
1.Top Quality Assurance:
Strict control and selection of materials;
2. Advanced Technology and Testing Measures
1.Q: Full price list for these products
A:If you need the price list for these products, please notify the product model so that i can quote you accordingly.
Please understand we have a very wide product range, we don't usually offer full products price list.
2. Q: Business terms
A:
Shipment time: 25-40days after your payment
Shipment: By sea
Loading port: qingdao port, China
Destination port: ...To be advised
Payment: By bank transfer
Warranty: 1 year
3. RE: CE
A: Most of our products are certified by CE.
4.Q:Sample test
A:Now our agri machines are exported in large quantity.
If you need one sample for test, we advise you to get this sample from the domestic dealers.
If you want to get from us directly, usually we advise to order at least one pallet per product.
5.Q:Why choose YJF for cooperation?
A: Comparing with our competitors, we have much more advantages as follows:
1.More Professional Sales staffs to guarantee the better service
2. More agri machines for your choice
3. More New products into your range to avoid price competion
4.Larger quantity production and shipment
6.Better quality to guarantee better Credit.
7.Faster delivery time:only45days
8.More stick quality checking before shipment.
9.More reasonable after-sales service terms.
10.More famous brand: YJF;
Welcome to contact us for more details!!!
