YT23 Rock Drill

Specifications

YT23 Rock Drill is a kind of high efficiency air leg rock drill machinery.

item name:YT23 Rock Drill



specification

Weight                    24 kg
Length                     628mm
Air pressure               0.63MPa
Cylinder dia               76mm
Impact frequencey          36Hz
Impact energy              65J
Air consumption            80L/S
Idel speed                 300r/min
Noise                      112dB(A)
Water pressure            0.2-0.3MPa
Air pipe (inner dia )      25mm
Water pipe (inner dia )    13mm
Bore dia                   34-42mm
Bore depth                 5m
Shank dimensions           22*108mm



The rock drill of YT23 is a kind of high efficiency air leg rock drill machinery. it is mainly used for blasting holes and other drilling works in a quarries, railway construction, water conservancy construction and defence project facility. When it is matched with the Model FY200A  Oil reservior and Model FT160A or FT160B Air-leg, it can perform wet drilling and blast holes from different and angles.
