Sullair Air filter element assy of Precision filter replacement  assy control valve

assy control valve

Separator filter (C )

For bulk liquid removal plus a 3 micron coalescer (5ppm w/w maximum remaining oil content).
Two-stage filtration
First stage—two stainless steel orifice tubes provide 10 micron mechanical separation.
Second stage—in-depth fiber media captures solid and liquid particles to 3 micron.

Air line filter (T)

For removal of liquid water and oil; removes solid particles to 1 micron (1.0 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores.
Two-stage filtration
First stage:captures larger particles with alternate layers of fiber media and media screen.
Second stage:coalesces aerosols and captures solid particles with multiple layers of epoxy bonded, blended fiber media.

High efficiency oil removal filter (A)

For coalescing fine water and oil aerosols; removes solid particles to 0.01 micron (0.01 ppm w/w maximum remaining oil content).
Corrosion resistant inner and outer cores.
Two stage filtration
First stage:multiple layers of bonded, blended fiber media for fine coalescence.
Second stage:multiple layers of bonded, blended fiber media for fine coalescence.
Outer coated, closed cell foam sleeve.

Ultra high efficiency oil removal filter (AA)

For coalescing ultra-fine oil aerosols; removes solid particles to 0.01 micron (0.001 ppm w/w maximum remaining oil content).
Corrosion resistant inner and outer cores.
Two stage filtration
First stage—coated, closed cell foam sleeve acts as pre-filter and flow disperser.
Second stage—multiple layers of matrix blended fiber media for ultra-fine coalescence.
Outer coated, closed cell foam sleeve.

Oil vapor removal filter (H)

For removal of oil and hydrocarbon vapors normally absorbable by activated carbon; removes solid particles to 0.01 micron (0.003 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
Two stage filtration
First stage—a stabilized bed of finely divided carbon particles removes the majority of the oil vapor
Second stage—multiple layers of fiber media with bonded micro fine carbon particles removes the remaining oil vapor
Multiple layers of fine media prevent particle migration
Outer coated, closed cell foam sleeve prevents fiber migration
Designed for 1000 hour life at rated conditions.

u        Easy replacement;

u        Stainless steel for added structural integrity low resistance to flow seam welded for extra strength.

u        Piston type elements to housing seal keeps unfiltered air from by-passing element.

 Shanghai Sunfilter Industry.Co.,Ltd.is a manufacturing company which is specialized in compressed air drying and purification equipment who's research,manufactory,sales and service.

the leading product is Refrigerated Air Dryer ,Desiccant Air Dryer ,Compressed Air Filter,Modular Regenerative Adsorption Compressed Air Dryer,Water Chiller .we have the CE certification and could provide the ASME code dryer for customer.

Sunfilter has been seeking excellence all the time . the company ushers in the Denmark France Japanese ect. Nations system cold and advanced technique,equipments and the original machine pieces,meanwhile taking the advanced designing concept and exquisite Production Process,following the ISO9001 quantity management system completely.

 we have been improving quality by good management,seeking development by innovation ,casting the brand in good faith,expanding the market in a win-win situtaion,our products not only throughout the country,but also export to Australia ,South America ,South America, Southeast Asia, Middle East, Europe and more than 30 Countries.

  Whether pre-sale, in sale, after-sale, as long as the user needs the help of equipment and technical advice, our company will provide the technical information within 24 hours for free, debugging boot on spot. Having finished the debug, our engineers are responsible for the operation training for the user's staff, receiving user equipment faiure notification.

1. Are you manufacturer or Trade Company?
We are  professional compressed air purifing and drying system factory, founded in 2005.

2. What's the order process?
a. Inquiry---provide us all clear requirements.
b. Quotation---official quotation form with all clear specifications.
c. Printing file--- PDF, Ai, CDR, PSD, the picture resolution must be at least 300 dpi.
d. Sample confirmation---digital sample, blank sample without printing or hardcopy.
e. Payment terms--- T/T 30% in advanced, balanced before shipment.
f. Production---mass production
g. Shipping--- by sea, air or courier. Detailed picture of package will be provided.

3. What terms of payment you use?
T/T, L/C
