Specifications
1.High tech over voltage protector2.Max power:6.6KVA
3.Delay time:2~3min
4.With LED indicator
5.safe operation
220V 60Hz Over Voltage Protector Safe Operation Long Lifetime
1.Overvoltage operation value:265V±5V
2.Undervoltage operation value:170V±5V
3.Delay time:2~3min
4.With LED indicator
INTRODUCTION:
At the top of the shield is the word "INPUT" Connect the neutral pole to the letter "N" and connect the positive or phase to the letter "L"
In the bottom of the shield is the word "output", connect the positive charge to the letter "L" and the neutral or return of the cargo to the letter "N". This may be connected to the electrical system directly or circuit breakers (Breakers)
The panel has a dual color LED indicates the working status of protector: when the current reaches the normal LED is green and when the current is above or below the distribution of allowed values
, is interrupted fully the energy and the LED glows red to protect equipment and electrical and electronic equipment connected to the network
This protector is mounted on a load center with DIN rail independently or in a load center where are the breakers that handle electrical distribution.
