Specifications
Full-auto Shrink Wrapping Film Packing Machine1.using PLC control
2.Shrinking,cooling
3.24 bottles in a pack for 550ml
24 bottles in a pack for 550ml
(Meets 3000bph to 15000bph filling line)
Model:JMB-250B Without Touch screen
Packing material maximum size: L600 × W400 × H350mm
Shrink film material: PE/ PVC / POF
Shrink film thickness :0.03-0 .15 mm
Thermal furnace maximum temperature: 160 – 260°C arbitrary regulation
The maximum capacity: 6-12 packages per minutes
Equipment power: 18Kw
The actual power: 15Kw / h
Power Requirements: 380/220V
Weight: 1.2T
Fan: 0.75Kw 380V 2 units; 65W 220V 4 units.
2) The equipment basic configuration:
7 inches touch screen, PLC control system AIRAC pneumatic component (1 set)
THINGET frequency converter (1 set)
Stainless steel wing type heating tube (12 pcs)
Teflon conveyor belt
Motor and worm transmission
Korea Autonics photoelectric switch, proximity switch.
Heat sealing knife cast aluminum heating board, temperature uniformity, long life, the company special made to order.
whole appearance of the spray, the frame adopts high-quality carbon steel, stainless steel body parts.
Length of bottle conveying machine: 2500mm
wooden and Stretch Film packaging separately.
3) The product description: Frequency converter adjusts speed , two-grade conveying bottle device.
Pushing the bottle, the heating, sealing and cutting entire operation adopts pneumatic mechanism.
Sensor switch control film length.
Touch screen, PLC control system has greatly increased the reliability of equipment operation. ouble Wind air circulation fan is to ensure the temperature balanced in shrinking area.
Large air flow cooling system is to ensure rapid stereotypes. High temperature Teflon fiberglass conveyor belt, transmission smooth, high strength wearesistant. requency conversion stepless timing belt conveyor. Conveyor height can be made according to user requirements, adjustment range ± 100mm
Conveying bottle machine meets the direction which the users required, may be extended or shortened
Wing-shaped stainless iron heating system is durable.
4) Technical conditions and requirements:
1 Packing form :
(1) 350/500/550/600ML-- Big packing: 4 × 6, 4 × 5 , Small packing : 3 × 4, 3 × 5 four types of packing.
(2) 1L/1.5L/2L/2.5L-- Big packing: 3 × 3, 3 × 4 , small packing: 2 × 2, 2 × 3 four types of packing.
2 Aimed at Easy Can is best way to adopt packaging with tray and after packaging is stable.
3 Packing speed :6-12 packages / min.
4 To meet the filling machine speed.
(1) 350/500/550/600ML--Big package: 4 × 6, 4 × 5, (12000-15000 bottles / hour), Small package: 3 × 5, 3× 4, (8000-10000 bottles / hour).
(2) 1L/1.5L/2L--Big package: 3 × 4, 3 × 3 (5000-6000 bottles / hour), Small package: 2 × 3, 2 × 2 (3000-4000 bottles / hour).
5 packaging materials: PE shrink film width (200-600mm), thickness (0.08-0.12mm)
Remark:
Total weight: about 1.2T
packing size(MM):shrink machine size: 3500*1000*1800,
Cut film part : 1100*1100*1960,
Conveyor part : 2600*800*750.
Free spare parts:
III.Finished products
