PET Bottle shrink wrapping machine/small bottles wrap packing machine/beverage bottles packing machine

1) The technical parameters:

Device Model: JMB-250A type

Packing material maximum size: L600 × W400 × H350mm

Shrink film material: PE/ PVC / POF

Shrink film thickness :0.03-0 .15 mm

Thermal furnace maximum temperature: 160 – 260°C arbitrary regulation

The maximum yield per minute :6-12 packages

Equipment power: 18Kw

The actual power: 15Kw / h

Power Requirements: AC 380/220V 50Hz

Weight: 1.2T

Fan: 0.55Kw/ 380V, 2 units; 65W /220V 4 units.

Technical conditions and requirements:

1 Packing form :

(1) 350/500/550/600ML-- Big package: 4 × 6, 4 × 5 , Small package: 3 × 4, 3 × 5

four types of packaging.

(2) 1L/1.5L/2L/2.5L-- Big package: 3 × 3, 3 × 4 , small packaging: 2 × 2, 2 × 3

four types of packaging.

2 Aimed at Easy Can, It's best way to adopt packaging with tray and after packaging is stable.

3 Packing speed :6-12 packages / min.

4 To meet the filling machine speed.

(1) 350/500/550/600ML--Big package: 4 × 6, 4 × 5, (12000-15000 bottles / hour),

Small package: 3 × 5, 3× 4, (8000-10000 bottles / hour).

(2) 1L/1.5L/2L--Big package: 3 × 4, 3 × 3 (5000-6000 bottles / hour),

   Small package: 2 × 3, 2 × 2 (3000-4000 bottles / hour).

5 packaging materials: PE shrink film width (200-600mm), thickness (0.08-0.12mm)

Standard functions: (three parts)

1, JMB-250A Automatic transmission organizations; butt filling machine conveyor belt, two levels, or a transmission, the drive control, speed adjustable, can be automatic bottle.

2, JMB-250A Automatic envelope sealing body to complete the set automatically by the packaging film and sealing functions.

3, JMB-250A Automatic thermal cooling mechanism; can automatically after the completion of mantle contraction and cooling.

Remark:

Total weight: about 1.2T

packing size(MM):shrink machine size: 3500*1000*1800,

Cut film part  : 1100*1100*1960,

Conveyor part : 2600*800*750.

III.Output with feeding tray or not
