Specifications
Independent electric box and tough screen controlAutomatic Bottle Conveying and Spliting System
LS/Panasonic/Mitsubishi PLC
Automatic Shrink Wrapping Packing Machine
(Model: JMB-250A)
1. Scope of Application:
Auto shrink- wrapping machine series are suitable for the package of bottled water ,beverage,household, electric appliances,electrical units,floor boards,pottery and so on.
2. Feature:
1) It can make package perfect whatever it is without pallet, cartoon, rectangle, round or flat shape.
2) It has the advantage of less cost and better appearance. It applies PLC automatic controller, man-machine interface, ensure that no fallen bottle, no bottle shortage.
3) Replace film conveniently. It has failure alarm, lock device, reliable running.
4) The whole machine applies super steel and stainless steel, with compact and endurable structure. This new type of wrapping machine is the ideal equipment for beverage filling line.
3. Technical Diameter:
Machine Dimension |
5050*3300*2100(L*W*H.mm) |
Max packed size |
600*400*350(L*W*H.mm) |
Shrinkage film material |
PE,PVC,POF. |
Shrinkage film thickness |
0.03-0.15(mm) |
Oven temperature |
160 - 260° |
Max output |
6-12Bag/Min. |
Actual Power |
15Kw/H. |
Voltage |
380V,3Phs |
Weight |
1.2T. |
Applicable Internal Diameter of Paper Tube |
5″~10″. |
4.Components List:
PLC(XIEJE,Canada joint venture brand/LG) |
Transducer(XIEJE,Canada joint venture brand) |
Cylinder, Solenoid Valve(AIR TAC) |
Proximity Switch, Photoelectricity Switch(Korea brand) |
Motor |
Conveying net belt |
Heating tube |
Intermediate relay(OMRON) |
5 Packing Type:
a) 350/500/550/600ML:Big package:4×6,4×5;Small package: 3×4,3×5.
b)1L/1.5L/2L/2.5L:Big package: 3×3,3×4;Small package: 2×2,2×3.
Pictures:
Electric Control Box & Tough Screen
Automatic Bottle Spliting & Convering
Heat Shrinking Part
