Supper Effective Solar Thermal Collector

Supper Effective Solar Thermal Collector photo-1
US$ 80 - 500 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Unpressurized
Circulation Type:
Direct / Open Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Type Evacuated Tube
Pressure Unpressurized
Circulation Type Direct / Open Loop (Active)
Heating System Thermosyphon (Passive)
Connection Type Split
Installation Wall Mounted
Housing Material Stainless Steel
Certification CE, Other, CE, ISO9001-2000,SRCC ,SGS ,solar keymark
Capacity 300
Place of Origin Jiangsu, China
Brand Name sunnergy solar water heating
Model Number SK-6

Specifications

Supper effective solar thermal collector
1.high efficiency
2.5 years warranty
3.OEM solar collector
4.CE ISO9001-2000,SRCC

Supper effective solar thermal collector

Changzhou sunnergy solar water heater co.,ltd,is specially engaged in research ,development,production and sales of solar water heaters and collectors and solar water tanks.

Product name: Supper effective solar thermal collector
Product size:
Product class: Solar Collector
Product Introduction:




Manifold  casing material: 304 stainless steel or powder coated aluminum
Frame material: 304 stainless steel
Heat-pipesilicone rubber
Maximum operating pressure: 6bar-85psi
material: C12200 COPPER
Rubber seals and rings: UV stabilized high temperature
Model
Absorbing Area (m2)
Heat pipe vacuum tube
Supply hot water(L)
Water Temperature(Centigrade)
Qty.per 20"/40" Container
Diameter (mm)
Length (mm)
Number
SNB-47/1500-12
1.2
47
1500
12
70
60
141/295
SNB-47/1500-15
1.5
47
1500
15
70
60
120/270
SNB-47/1500-18
1.8
47
1500
18
120
60
95/198
SNB-47/1500-20
2.0
47
1500
20
120
60
85/178
SNB-47/1500-24
2.4
47
1500
24
150
60
71/148
SNB-47/1500-30
3.0
47
1500
30
180
60
57/120
SNB-58/1800-12
1.99
58
1800
12
110
60
123/258
SNB-58/1800-18
2.66
58
1800
18
150
60
82/172
SNB-58/1800-20
2.98
58
1800
20
175
60
73/155
SNB-58/1800-24
3.56
58
1800
24
220
60
56/118
SNB-58/1800-30
4.43
58
1800
30
260
60
45/96





Supper effective solar thermal collectorSupper effective solar thermal collectorSupper effective solar thermal collectorSupper effective solar thermal collectorSupper effective solar thermal collectorSupper effective solar thermal collectorSupper effective solar thermal collectorSupper effective solar thermal collector
