Solar Geysers Water Heaters Solar Heating

Solar Geysers Water Heaters Solar Heating photo-1
US$ 30 - 650 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Unpressurized
Circulation Type:
Direct / Open Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Type Evacuated Tube
Pressure Unpressurized
Circulation Type Direct / Open Loop (Active)
Heating System Thermosyphon (Passive)
Connection Type Other, Direct-Plug, Direct-Plug
Installation Freestanding
Housing Material Stainless Steel
Certification CE, CE, Other, CE, CE, ISO9001-2000,SRCC ,SGS ,solar keymark
Capacity 100
Place of Origin Jiangsu, China
Brand Name SUNNERGY Solar heating, SUNNERGY
Model Number SN SERIES

Specifications

Solar geysers water heaters solar heating
Non-pressurized Type
5 years quality warranty
OEM water heater
CE ISO9001-2000 SGS

Solar Geysers Water Heaters Solar Heating

Changzhou sunnergy solar water heater co., ltd .is specially engaged in research ,development ,production and sales of solar water heaters and collectors and solar water tanks.

Product name: evacuated tube solar water heater
Product size:
Product class: Unpressurized Type
Product Introduction:

Stainless Steel System:
1. Material of Inner tank: SUS304-2B stainless steel with 0.4mm thickness
2. Material of Outer tank: SUS304-2B stainless steel with 0.31mm thickness
3. Magnetic-controlled Al-N-Al splash all glass evacuated heat-collecting tubes, fast heat absorbing and temperature risen
4. Heat Preservation Layer:55mm polyurethane integral foaming, superior heat preservation
5. Material of support:Stainless Steel Profiled Bar with 1.2mm thickness

Model
Absorbing Area
(m2)
Glass Vacuum Tube
Tank Capability
(L)
Loading Qty(sets)
20"/40"
Ø(mm)
L(mm)
NO.(PCS)
420-1500/47-15-C
0.75
47
1500
15
85
66/137
420-1500/47-18-C
0.90
47
1500
18
100
56/115
420-1500/47-20-C
1.00
47
1500
20
111
50/105
420-1500/47-24-C
1.20
47
1500
24
135
44/92
420-1500/47-30-C
1.50
47
1500
30
166
36/75
470-1500/47-15-C
0.75
47
1500
15
113
51/102
470-1500/47-18-C
0.90
47
1500
18
140
44/88
470-1500/47-20-C
1.00
47
1500
20
150
42/84
470-1500/47-24-C
1.20
47
1500
24
180
33/66
470-1500/47-30-C
1.50
47
1500
30
230
30/60
470-1800/58-16-C
1.28
58
1800
16
133
44/91
470-1800/58-18-C
1.44
58
1800
18
150
39/81
470-1800/58-20-C
1.60
58
1800
20
165
35/73
470-1800/58-24-C
1.92
58
1800
24
200
30/62
470-1800/58-30-C
2.40
58
1800
30
250
24/50

Solar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heatingSolar geysers water heaters solar heating
