5-port VLAN Gigabit Fast Ethernet Desktop Network Switch(5 10/100/1000M RJ45 ports,plastic case)

Software Specification

Standards and Protocols

IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3ad, 802.3x, 802.1q, 802.1p

Basic Function

MAC Address Auto-Learning and Auto-aging

Storm Control (Broadcast, Multicast, Unknown unicast)

Limit Rate

Port Mirroring

MAC Address Table

8k

Switching Capacity

10Gbps

Transmission Method

Store-and-Forward

Priority

Port based Priority

IEEE 802.1p based Priority: 4 Queues

IP DSCP based Priority

Link Aggregation

IEEE 802.3ad LACP Link Aggregation

VLAN

Port Based VLAN

802.1Q Tag-VLAN

MTU VLAN

Hardware Specification

Ports

5 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e cable (maximum 100m)

1000BASE-X: MMF, SMF

LED Indicators

Power, System, Link/Act, 1000M,

Safety & Emission

FCC, CE

Dimensions (W*D*H)

11.6*7.1*1.7 in. (294*180*44 mm)

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Power

100-240VAC, 50/60Hz
