Specifications
1.The 24st is uplink port, Other port communication with each other.2.Supports MAC address auto-learning and auto-aging
Software Specification | |
Standards and Protocols |
IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3ad, 802.3x, 802.1q, 802.1p |
Basic Function |
MAC Address Auto-Learning and Auto-aging |
Storm Control (Broadcast, Multicast, Unknown unicast) | |
Limit Rate | |
Port Mirroring | |
MAC Address Table |
4k |
Switching Capacity |
4.8Gbps |
Transmission Method |
Store-and-Forward |
Priority |
Port based Priority |
IEEE 802.1p based Priority: 4 Queues | |
IP DSCP based Priority | |
Link Aggregation |
IEEE 802.3ad LACP Link Aggregation |
VLAN |
Port Based VLAN |
802.1Q Tag-VLAN | |
MTU VLAN | |
Hardware Specification | |
Ports |
24 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) |
Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
LED Indicators |
Power, System, Link/Act, 100M, 1000M, |
Safety & Emission |
FCC, CE |
Dimensions (W*D*H) |
17.3*7.1*1.7 in. (440*180*44 mm) |
Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) |
Power |
100-240VAC, 50/60Hz |
