CONTAINER FUEL STATION

Specifications

MOBILE SERVICE STATIONS are complete Service Station closed inside an ISO container, for dispense and storage 14.200 or 40.000 l

CONTAINERISED SERVICE STATIONS - MOBILE SERVICE STATIONS



General description:

The MOBILE SERVICE STATIONS are complete Service Station closed inside an ISO container, for dispense and storage 14.200 or 40.000 liters of 1 or 2 products (Diesel or/and Gasoline). Custom designed according the client needs.

Can be moved easily and can be closed safely. Easy and fast commissioning and reduced works.



Specifications:

-Cabinet made from 1st trip ISO Container Dry-Van 20' or Dry-Van 40'. Equipped with ventilation grids, Removable Ladder, Roof’s Access Cover to tank’s manhole, Retention Tray and non-slip grating under dispenser area.

-Double Wall Tank, fully tested and certified according BS EN 12285-2 Class A, with leak detector.

-Steel piping welded and tested.

-Suction Line 1.1/2” equipped with a mesh filter, anti siphon valve and cut valve.

-Fuel Loading line 4”, inlet near dispenser area, with CAMLOK connection, down pipe and overfill prevention valve adjusted at 95% of tank’s capacity.

-Venting: 2” vent pipe with atmospheric vent valve and filter.

-Pneumatic level gauge, dipstick and capacity table.

-Internal Lighting

-Dispenser TOKHEIM or DRESSER WAYNE

-Warranty period of the tank, piping, saddles, and access covers: 3 years

-Warranty period of the dispenser, valves, gaskets, gauges and fittingsaccording to manufacturer.



Options:

-Basic Mobile Diesel Service Station with 14.200L tank and 40L/min Dispenser.

-Basic Mobile Diesel Service Station with 40.000L tank and 40L/min Dispenser.

-Gasoline Equipment (Grounding and Vapour Recovery Stage I)

-Complete Double tank compartment , with dispenser, piping and valves

-Unloading pump (500L/min) with valves and piping

-Electric Generator

-External lighting

-Integrated Office
