Specifications
centrifugal fan drying1. high temperature
2.high efficiency
3.easy to operate
mpt delivery
Backward curved blade electric Metallurgy blower
Welcome To Henan Hengtong Blower CO.,LTD
Hengtong Blower produces in each big industries used as key equipment, among dust removal blower, boiler blower, cement plant dedicated blower, Metallurgy blower, environmental protect blower etc were used in industrial and civil fields.
Application
mining |
Hengtong Blower Corporation’s pre-engineered and custom Metallurgy blowers are designed and manufactured for mining industry operations all around the world. mining industry need to both axial and centrifugal designs for spark-resistant underground applications. ventilations exhaust, and supply systems are used throughout mining applications for dust control, mineral processing, and braking systems such as crushers, drillers and grinders. |
manufacturing facilities |
Hengtong blower Co. Ltd. designs and manufactures ventilations supply and exhaust all types of the industrial air, our fans keep safe and comfortable working environment and prevent the volatile air staying within the equipment. Hengtong Blower’s pre-engineered and custom Metallurgy blowers meet the requirements of manufacturing facilities and their processes. |
coal |
Hengtong Blower has designed and engineered a wide array of high quality pre-engineered and custom heavy duty fans used in the coal manufacturing industry. Our spark resistant and abrasion resistant fans are designed by boiler and burner manufactures to provide recirculation and air exhaustion within these systems Other applications of our aircrafts are used for pneumatic conveying and dust collection system. In addition, Hengtong Blower supplies products for general ventilation and exhaust system. |
General Ventilation |
Hengtong blower designs and manufactures an array of pre-engineered and custom Metallurgy blowers for various industries to ensure proper ventilation .from airfoil fans to backward inclined fans, we provide highest performance with efficiency and versatility that match to your requirements, our air handing products supply clean air and exhaust unwanted and heated air out of the airflow so as to create an cosy and safe working environment. |
Mian produce
Hengtong blower custom-engineered Metallurgy blowers suppliers are designed specifically for each contract which allows us to apply a combination of experience, advanced design techniques and a knowledge of the operating conditions to select the optimum fan in terms of capital cost, running cost, maintainability and reliability. A wide range of options are available in terms of drive arrangement, output control, layout and ancillary equipment, to give maximum flexibility to the plant designer.
Recommended parts
Casing: Rugged enclosure design, selection of appropriate electrode for welding high-strength , ensure that housing more durable.
Impeller :Impeller annealed completely eliminate welding stress generated when the structure to ensure that the shape of the impeller does not occur creep and cracks.
Air inlet: Convergence can be a good design to reduce wind resistance, and to be able to get better gas inlet angle when entering the impeller wheel, can effectively improve the operating efficiency of the fan.
Overall support:Overall support is your installation is very simple and easy operation
Motor:General motor, high voltage, frequency conversion motor or custom is appropriate for your system
Belt pulley: The structure is compact save a space ,differential transmission.
Optional components
Our Principle
Metallurgy blower driven by motor, drive the impeller rotation, the gas along the air inlet get into the impeller, as a result of the action of the impeller, the gas gain energy, pressure and kinetic energy increased, the impeller gas out of the volute impeller junior people after work, leave is the role of volute impeller gas concentration of diversion, and parts of the gas kinetic energy into the static pressure, and then send the gas from the outlet of the spiral case, when the gas enough energy to overcome the resistance of pipelines and gas can be transported to high or the distance.
Technical Parameters
| Application | Temperature | Normal temperature Air | |||
| Hot Air | |||||
| Air composition | Clean air | ||||
| Dusty air | |||||
| Corrosive gas | |||||
| Combustible gas | |||||
| Powder materials | |||||
| Light particle materials | |||||
| Performance | Impeller diameter | 400 | ~ | 2000 | mm |
| Speed of mainshaft | 960 | ~ | 4000 | rpm | |
| Pressure range | 251 | ~ | 4500 | Pa | |
| 1 | ~ | 33 | mmHg | ||
| 25 | ~ | 459 | mmH2O | ||
| Flow range | 220 | ~ | 221730 | m3/h | |
| 373 | ~ | 376899 | CFM | ||
Production process
Installation service
There are three methods for our installation service:
Quality Assurance:
Hengtong's Quality Control programe is backed by a comprehensive Quality
Management System (ISO 9001:2000), deviced at the time of inception and
continuously upgraded. We have in place highly mechanised testing facilities, with procedures laid out to the requirement standards. The test facilities in
place permit the flawless testing of the complete range of our products.
customer visitting
our blower export to Vietnam, Libya, the Philippines, Albania, Romania, Pakistan, India, EU and other countries and regions, which has won the domestic and foreign customers and several design institutes broad trust and praise.
We will appreciate it a lot if you can offer us your product performance requirement and operation environment for the centrifugal air blowers suppliers of you need,so that we can customize optimal product to meet your every requirement.
Air volume/air flow |
|
m3/h |
Total pressure or static pressure |
|
Pa |
Medium temperature |
|
℃ |
Voltage |
|
v |
Frequency |
|
Hz |
Altitude of operation place |
|
m |
If you are interested in our centrifugal air blowers suppliers, Please don't hesitate to visit our website.
htblower.en.china.cn
We will give you a favorable price. .
