Hydraulic scissor lift is mainly used in flat indoor or outdoor. It features imported hydraulic components, explosion-proof pipe unit and emergency descending unit; hydraulically driven travelling function; low in noises and free of air pollution; durable, chip-free, skid-proof and traceless tires without scratching the ground.
Technical parameters
Modelw |
GTJZ1012 |
|
Measurements |
Metric | US |
Dimensions | ||
Platform height max. |
10 m |
33 ft |
Working height max. |
12 m |
39 ft |
Platform extended |
0.9 m |
3 ft |
Length-stower |
2.39 m |
7 ft 8 in |
Width-stower |
1.15 m |
3 ft 8 in |
Height-folding guardrails |
2.48 m |
8 ft 1 in |
Height-rails folded |
1.86 m |
6 ft 1 in |
Height-fixed rails |
2.48 m |
8 ft 1 in |
Ground clearance |
0.1 m |
3 in |
Wheelbase |
1.87 m |
6 ft 1 in |
Platform size(L*W*H) |
2.25 m *1.15 m *1.1 m |
7 ft 4 in *3 ft 8 in *3 ft 6 in |
Productivity | ||
Max. platform occupancy |
2(indoor) 1(outdoor) |
2(indoor) 1(outdoor) |
Lift capacity |
320 kg |
705 lbs |
Lift capacity-extension deck |
120 kg |
265 lbs |
Drive speed-stowed |
0~3.2 km/h |
0~2 mph |
Drive speed-raised |
0~0.8 km/h |
0~0.5 mph |
Gradeability |
25% |
25% |
Turning radius-inside |
0 m |
0 ft |
Turning radius-outside |
2.35 m |
7 ft 7 in |
Raise/ Lower speed |
55/ 42 s |
55/ 42 s |
Controls |
Proportional |
Proportional |
Drives |
Dual front wheel |
Dual front wheel |
Brakes |
Dual rear wheel |
Dual rear wheel |
Tire size(solid non-marking) |
380 mm * 125 mm |
15 in * 5 in |
Power | ||
Power source |
24V DC (4*6V, 225Ah batteries) |
24V DC (4*6V, 225Ah batteries) |
Hydraulic system capacity |
18 L |
4.76 gal |
Power |
3 KW |
3 KW |
Weight | ||
Indoor |
2380 kg |
5247 lbs |
Indoor & outdoor general |
2570 kg |
5666 lbs |
Standards Compliance |
CE/ISO/ADR/ARAMCO |
CE/ISO/ADR/ARAMCO |
