Help CenterDiesel Self-propell Scissor Lift With 680kg Large Capacity
Related Products
-
High Quality Movable Hydraulic Scissor Lift With CENegotiableMOQ: 1 Unit -
Self-propelled Electric Hydraulic Scissor Lift PlatformNegotiableMOQ: 1 Unit
-
Four-wheel Mobile Scissor Lift With Low PriceNegotiableMOQ: 1 Set
-
Hull Cleaning Equipment 6M Scissor LiftNegotiableMOQ: 1 Set
-
High Rise Scissor Lift With CENegotiableMOQ: 1 Unit
Self-propelled hydraulic scissor lift is mainly used in flat indoor or outdoor. It features imported hydraulic components, explosion-proof pipe unit and emergency descending unit; hydraulically driven travelling function; low in noises and free of air pollution; durable, chip-free, skid-proof and traceless tires without scratching the ground.
Technical parameters
Models |
GTJZ0818D |
|
Dimensions | ||
Platform height max. |
25.9 ft (7.9 m) |
|
Working height max. |
32 ft (9.9 m) |
|
Platform extended |
4.92 ft (1.5 m) |
|
Overall Length(stowed,with outrigger/without) |
12ft/10.8ft(3.77m/3.29m) |
|
Overall width(stowed) |
5.77 ft (1.76 m) |
|
Overall height (stowed,guardrail folded/unfolded) |
6 ft (1.9 m)/8.2ft(2.50m) |
|
Wheelbase |
7.48 ft (2.28 m) |
|
Ground Clearance |
0.72 ft (0.22 m) |
|
Platform size (L*W*H) |
9 ft*5.24ft*3.6ft (2.8 m*1.6 m*1.1 m) |
|
Productivity | ||
Max. platform occupancy |
4(indoor), 4(outdoor) |
|
Lift capacity |
1499 lbs (680 kg) |
|
Lift capacity - extension outreach |
308 lbs (140 kg) |
|
Driving speed - stowed |
0~5.6 km/h |
|
Driving speed - raised |
0~0.48 km/h |
|
Gradeability |
40% |
|
Turning radius - inside |
6.9 ft (2.11 m) |
|
Turning radius - outside |
15 ft (4.6 m) |
|
Rising / Falling speed (without loading) |
29s~39s / 26s~36s |
|
Controls |
Proportional |
|
Drive&steer model |
4WD*2WS |
|
Hydraulic system pressure |
24Mpa |
|
Tire Size/type |
26*12-16.5/solid foam |
|
Power | ||
Control voltage |
12VDC |
|
Hydraulic system tank vol. |
85 L |
|
Fuel tank vol. |
48 L |
|
Weight | ||
Overall weight (with outrigger/without) |
8631 lbs (3915 kg) / 7617 lbs (3455 kg) |
|
StandardsCompliance |
CE/ISO/ADR/ARAMCO |
|
