FS-6302 PP Float Level Sensor For Water Dispenser
Switch characteristic:
Contact form: A(Normally Open)
Max Contact rating: 10W
Max switch voltage: 100V
Max switch current: 0.5A
Max contact resistance: 100m Ohm
Min insulation resistance: 100M Ohm
Electrical Life: 1x107 (5Vdc, 10mA)
Physical characteristic:
Min shock: 30G
Min vibration: 30G(10~50Hz)
Temp. rating: -10~+60°C
Heat Shock: -20~+70°C
Widely applied on the water dispenser.
Switch Characteristic |
Physical Characteristic |
1. Contact Form: A (Normally Open) |
1. Min Shock: 30G |
2. Max Contact Rating: 10W |
2. Min Vibration: 30G(10~50Hz) |
3. Max Switch Voltage: 100V |
3. Temp. Rating: -10~+60°C |
4. Max Switch Current: 0.5A |
4. Heat Shock: -20~+70°C |
5. Max Contact Resistance: 100m ohm |
|
6. Min Insulation Resistance: 100M ohm |
|
7. Electrical Life: 1x107 (5Vdc, 10mA) |
|
