Self-propelled hydraulic mobile lift platform is designed in the concept of solidity and durability and good performance to provide a safe and reliable aerial work platform for customers. It applies to even very tough conditions. The vehicle can travel by itself flexibly during aerial operation (maximum working height is 44 meters). It is large in operation range, high in efficiency, powerful in driving force and large in load capacity. Meanwhile, it can hold 2-3 operators and working devices. The maximal gradeability can be up to 40%, so it can be parked and restarted on such slope without down sliding. This product is widely used for ship industry (shipbuilding and repairing), large-sized steel structure (steel structure manufacturing), construction engineering, urban utilities and gardening, airport and harbor, curtain wall engineering, petrochemical industry, etc.
Technical parameters
Models |
GTBZ20 |
GTBZ22J |
GTBZ26 |
GTBZ28J |
GTBZ30 |
GTBZ32J |
GTBZ36 | GTBZ38J | GTBZ42J |
Platform height max. |
20.6m |
22.2m |
25.8m |
27.7m |
30.4m |
32m |
36.5m | 38.1m | 41.6m |
Working height max. |
22.6m |
24.2m |
27.8m |
29.7m |
32.4m |
34m |
38.5m | 40.1m | 43.6m |
Horizontal extended |
17.5m |
18m |
22m |
21m |
22.3m |
24.4m |
21m | 22.5m | 24.38m |
Lift Capacity |
480kg |
250kg |
480kg |
250kg |
480kg |
250kg |
480kg | 250kg | 480kg |
Gradeability |
30%(2WD) 45%(4WD) |
30%(2WD) 45%(4WD) |
30%(2WD) 45%(4WD) |
30%(2WD) 45%(4WD) |
42% | 42% | 40% | 40% | 40% |
Length-stowed |
9.57m |
11.2m |
11.54m |
13.22m |
13m |
14.02m |
12.5m | 14.02m | 13.1m |
Width-stowed |
2.49m |
2.49m |
2.49m |
2.49m |
2.49m |
2.49m |
2.49m | 2.49m | 2.49m |
Height-stowed |
2.84m |
2.84m |
2.88m |
2.88m |
3.08m |
3.08m |
3.08m | 3.08m | 3.05m |
Ground clearance |
0.45m |
0.45m |
0.41m |
0.41m |
0.43m |
0.43m |
0.43m | 0.43m | 0.65m |
Wheelbase |
2.49m |
2.49m |
3m |
3m |
3.66m |
3.66m |
3.66m | 3.66m | 3.81m |
Platform size (L*W*H) |
1.45*0.85* 1.24m |
1.45*0.85* 1.24m |
1.45*0.85* 1.24m |
1.45*0.85* 1.24m |
1.45*0.85* 1.24m |
1.45*0.85* 1.24m |
1.45*0.85* 1.24m |
1.45*0.85* 1.24m |
2.44*0.91* 1.14m |
Production Line
Product Inventory
Application
Worldwide Show
About Us
Sinoboom is engaged in research, development, manufacturing, sale and service of aerial work equipment. There are four series of aerial work platforms, including articulated boom lift, telescopic boom lift, scissor lift and spider lift, with working height from 4M - 42M in full series and various types, we owns the proprietary core technology and 30 items of intellectual property.
Contact Us
Hunan Sinoboom Heavy Industry Co., Ltd.
No. 128, East Of Jinzhou Avenue, Jinzhou New District, Ningxiang County, Changsha, Hunan, China
Tel: 0086-731-87116222
Skype:
Why Choose Us
1. Provide a various kinds of aerial work platform, which could meet customer's needs.
2. We could help customer choose the right model and also provide customization.
3. All electrical elements are used world famous brand.
4. Provide timely delivery,Sales engineers are ready to solve all problem.
5. Provide spare parts, worksite installation guidance and training operation.
2. Presale service: Free comprehensive and detailed technology consultancy in construction sites, referential programs for construction equipment and the most suitable product program.
3. In sale service: We provide free guidance of installation and debugging and free training of operation, care and maintenance.
4. After-sale service: One-year warranty service of whole machine and lifetime maintenance; regularly markets visits and free guidance of whole machine’s maintenance and reparations.
5. Quick responses: we have a complete service network, 400 free hotline services for 24hours and assist you to solve the problem in a short time.
6. Parts supply: we have a complete parts supply network and can guarantee sufficient parts reserves and timely supply.
1. QTY?(set)
2. Purchase period?(in a month, two month, three months or others)
3. Delievery Time?(in a month, two month, three months or others)
4. Trade term? ( FOB/CIF to your nearest seaport)
5. Demand Working Height?
6. Demand Platform Size?
7. Platform load capacity?
8. Demand power source?(electric or hydraulic)
9. Demand drive motion?(2 wheel driving or 4 wheel driving)
10. Cooperation property?(dealer, agent, end-user, including company or personal use )
11. Application field?(construction, shipyard, industiral, airport, municipal garden
or others)
We'll give you an exact quotation based on your demand after confirming the above information.
