Help CenterPT LZT 1160; Electromagnetic Radiation Tester;radiation Tester
Related Products
-
PT-DT-9501; New Nuclear Radiation DetectorUS$ 1 - 1,145MOQ: 1 Set -
PT-WSB - VI; Smart Whiteness Meter Station;whiteness Meter Station;US$ 1 - 738MOQ: 1 Set
-
NK Series; Pull-push Gauge;Tension Meter;Handheld Tension Meter;US$ 1 - 50MOQ: 1 Set
-
PT-HP-5; Pull-push Gauge;Tension Meter;Handheld Tension Meter;US$ 1 - 350MOQ: 1 Set
-
PT-HP-s; External Type Digital Tension Meter;pull-push Gauge;Tension Meter;Handheld Tension Meter;US$ 1 - 550MOQ: 1 Set
Specifications
1. Reading showed: 3-1/2 a liquid crystal display2. est frequency width, frequency of 5 - 400 KHZ
3. Sampling time: 0.3 sec.
LZT – 1160; Electromagnetic radiation tester
1,Product overview:
LZT - 1160 tester is a new multi-functional electromagnetic radiation, electromagnetic radiation testing equipment, realize the high frequency radiation low-frequency radiation and relatively accurate test. High frequency is used to test and understand mobile phone, mobile phone towers, wireless devices such as electromagnetic radiation; Radiation, low frequency test magnetic field is used to test and understand household appliances, computer, cable, high tension line, substation, conductive electricity, power supply equipment such as electromagnetic radial. According to the test results to reasonable processing or effective avoid electromagnetic radiation, let users in electromagnetic radiation around you do fully understand.
2, instruments and technical characteristics:
Has simple operation, easy to test.
Derive value, easy to carry.
Has targeted, high frequency/low frequency divider tests.
Cardiac function is perfect, but numerical peak locking, lock.
Cardiac beautifully designed, professional appearance.
Derive the design comply with CE.
3, apparatus, application scope:
1. The high frequency electromagnetic radiation test applications: wireless router, the mobile phone, mobile phone towers, TV signal tower, radio towers, etc in equipment testing technical indicators all electromagnetic radiation source.
2. Low frequency electromagnetic radiation test applications: computers, TVS, printers, fax machines, air conditioners, refrigerators, stereos, washing machines, electric wire, power supply, the instrument test technology indexes such as electricity, electricity, power supply, all electromagnetic radiation source.
4, technical indicators:
Size: 132 mm (length) x 69 mm (width) x 31 mm (thickness)
Weight: 140 g
Reading showed: 3-1/2 a liquid crystal display
Profile: low frequency - mu T (micro tesla); High frequency - mu W/cm2 (microwatts per square centimeter)
Fine degrees: low-frequency: 0.01 mu T; High frequency: 1 mu W/cm2
Quantity process: low frequency: 0.01-19.99 mu mu T T; High frequency: 1 mu W/cm2-1999 mu W/cm2
Test frequency width, frequency of 5 hz - 400 KHZ; High frequency of 30 MHZ to 3000 MHZ
Sampling time: 0.3 seconds
Sensor head: single shaft (instruments) at the top
Overload tip: LCD displays "OL"
Operating temperature: 15 °C - + 60 °C
Working humidity: relative humidity below 80%
Operating voltage: 9 v (6 making 9 v battery)
