Industrial hydraulic scissor lift working platforms,self-propelled scissor lift manufacturers,move hydraulic scissor mobile lift
- 2000 Unit / Units per Month
- Chinese main ports
- T/T
Product Details
Place of Origin: | Hunan, China | Brand Name: | SINOBOOM | Model Number: | GTJZ1012 |
Product Description
Hydraulic scissors lift working platform is mainly used in flat indoor or outdoor. It features imported hydraulic components, explosion-proof pipe unit and emergency descending unit; hydraulically driven travelling function; low in noises and free of air pollution; durable, chip-free, skid-proof and traceless tires without scratching the ground.
Technical parameters
Modelw | GTJZ1012 | |
Measurements | Metric | US |
Dimensions | ||
Platform height max. | 10 m | 33 ft |
Working height max. | 12 m | 39 ft |
Platform extended | 0.9 m | 3 ft |
Length-stower | 2.39 m | 7 ft 8 in |
Width-stower | 1.15 m | 3 ft 8 in |
Height-folding guardrails | 2.48 m | 8 ft 1 in |
Height-rails folded | 1.86 m | 6 ft 1 in |
Height-fixed rails | 2.48 m | 8 ft 1 in |
Ground clearance | 0.1 m | 3 in |
Wheelbase | 1.87 m | 6 ft 1 in |
Platform size(L*W*H) | 2.25 m *1.15 m *1.1 m | 7 ft 4 in *3 ft 8 in *3 ft 6 in |
Productivity | ||
Max. platform occupancy | 2(indoor) 1(outdoor) | 2(indoor) 1(outdoor) |
Lift capacity | 320 kg | 705 lbs |
Lift capacity-extension deck | 120 kg | 265 lbs |
Drive speed-stowed | 0~3.2 km/h | 0~2 mph |
Drive speed-raised | 0~0.8 km/h | 0~0.5 mph |
Gradeability | 25% | 25% |
Turning radius-inside | 0 m | 0 ft |
Turning radius-outside | 2.35 m | 7 ft 7 in |
Raise/ Lower speed | 55/ 42 s | 55/ 42 s |
Controls | Proportional | Proportional |
Drives | Dual front wheel | Dual front wheel |
Brakes | Dual rear wheel | Dual rear wheel |
Tire size(solid non-marking) | 380 mm * 125 mm | 15 in * 5 in |
Power | ||
Power source | 24V DC (4*6V, 225Ah batteries) | 24V DC (4*6V, 225Ah batteries) |
Hydraulic system capacity | 18 L | 4.76 gal |
Power | 3 KW | 3 KW |
Weight | ||
Indoor | 2380 kg | 5247 lbs |
Indoor & outdoor general | 2570 kg | 5666 lbs |
Standards Compliance | CE/ISO/ADR/ARAMCO | CE/ISO/ADR/ARAMCO |
The core configuration
Production Line
Product Inventory
Application
Worldwide Show
About Us
Sinoboom is engaged in research, development, manufacturing, sale and service of aerial work equipment. There are four series of aerial work platforms, including articulated boom lift, telescopic boom lift, scissor lift and spider lift, with working height from 4M - 42M in full series and various types, we owns the proprietary core technology and 30 items of intellectual property.
Contact Us
Hunan Sinoboom Heavy Industry Co., Ltd.
No. 128, East Of Jinzhou Avenue, Jinzhou New District, Ningxiang County, Changsha, Hunan, China
Tel: 0086-731-87116222
Skype:
Why Choose Us
1. Provide a various kinds of aerial work platform, which could meet customer's needs.
2. We could help customer choose the right model and also provide customization.
3. All electrical elements are used world famous brand.
4. Provide timely delivery,Sales engineers are ready to solve all problem.
5. Provide spare parts, worksite installation guidance and training operation.
1. Service concept: Exceed clients’ expectation.
2. Presale service: Free comprehensive and detailed technology consultancy in construction sites, referential programs for construction equipment and the most suitable product program.
3. In sale service: We provide free guidance of installation and debugging and free training of operation, care and maintenance.
4. After-sale service: One-year warranty service of whole machine and lifetime maintenance; regularly markets visits and free guidance of whole machine’s maintenance and reparations.
5. Quick responses: we have a complete service network, 400 free hotline services for 24hours and assist you to solve the problem in a short time.
6. Parts supply: we have a complete parts supply network and can guarantee sufficient parts reserves and timely supply.
1. QTY?(set)
2. Purchase period?(in a month, two month, three months or others)
3. Delievery Time?(in a month, two month, three months or others)
4. Trade term? ( FOB/CIF to your nearest seaport)
5. Demand Working Height?
6. Demand Platform Size?
7. Platform load capacity?
8. Demand power source?(electric or hydraulic)
9. Demand drive motion?(2 wheel driving or 4 wheel driving)
10. Cooperation property?(dealer, agent, end-user, including company or personal use )
11. Application field?(construction, shipyard, industiral, airport, municipal garden
or others)
We'll give you an exact quotation based on your demand after confirming the above information.
