Specifications
1.Measuring parameters: Ra, Rz2.Accuracy: not more than plus or minus 10%
3.Evaluation of length: 1 ~ 5 l choose
PT-T6200 roughness instrument
Product features:
1. Multiple parameter measurement: Ra. Radio zamaneh. Rq. Rt; High precision inductance sensor;RC, PC - RC. GAUSS. D - P
2. Four kinds of filtering approach; Built-in lithium ion rechargeable batteries and charging control circuit, high capacity; Electromechanical integration design, small size, light weight, easy to use and built-in standard RS232 interface can communicates with the PC; With functions of automatic shutdown. This table has two ways shutdown: one for manual shutdown, another 5 minutes to turn it off for the keyboard operation.
3. This table to memory 7 group of measurement data and arrange another time to check the measurement conditions or even machine processing; With functions of metric system transformation.
4. SRT6200 roughness instrument technology parameters, display: blue backlight, four digital display, 10 mm LCD
Parameter:
1. Measuring parameters: Ra, Rz
2. Measuring range: Ra: 0.05 400.0 0.05 10.00 um/uinch Rz: uinch. 0.020 100.0 um / 0.780-4000
3. Accuracy: not more than plus or minus 10%
4. Volatility: value is not greater than 6%
5. Sensors: measuring principle: inductive radius: 10 microns , materials: 6. diamond load: 16 mn (gf) 1.6 ; Angle: 90 Deg.; vertically radius: 48 mm
7. Maximum driving trip: 17.5 mm / 0.7 inch sample length l (optional) : 0.25 mm, 0.8 mm, 2.5 mm
8. Drive speed: when measuring when sampling length = 0.25 mm, n = 0.135 mm/s when sampling length = 0.8 mm, n = 0.5 mm/s when sampling length = 2.5 mm, n = 1 mm/s return when n = 1 mm/resolution: 0.001 mu m when the measured value < 10 microns 0.01 mu m when 10 microns or less measured value < 100 mu m 0.1 mu m when measured value 100 mu m or higher
9. Evaluation of length: 1 ~ 5 l choose
10.Power: built-in lithium ion rechargeable battery 1 piece.
11. Working conditions: temperature: 0 ~ 50 °C
12. Humidity: < 85% RH
13. Overall dimensions: 140 x 52 x 48 mm
14. Net weight: 420 g
