Help CenterADS1102CNL Digital Storage Oscilloscope ,bandwidth 100 ,7 Inch Screen
Related Products
-
EPX-7500 Gold & Diamond Long Range DetectorUS$ 1 - 1,000MOQ: 1 Piece -
PT-453;Three Axis Motion Platform;motion Platform;motion Unit;US$ 1 - 500MOQ: 1 Set
-
EPX7500 Gold & Diamond DetectorUS$ 1 - 1,000MOQ: 1 Piece
-
Pro-Pointer Metal Detector Pinpointer for Gold Relic Coin PropointerUS$ 1 - 50MOQ: 1 Piece
-
MCD-2001 Pinpointing Metal DetectorUS$ 1 - 80MOQ: 1 Piece
Specifications
1.the technical specifications2.Bandwidth:100MHZ
3.Channel:channel +1 external trigger
4.Storage depth: single channel 40K
Feature:
1.Digital oscilloscope compact design, flexible operation; Using color TFT LCD and pop-up menu displays, implements its ease of use, greatly improving the user's work efficiency. Moreover, ADS1000 series of excellent performance, powerful, affordable. With high cost performance. Gsa ADS1000 real-time sampling rate is as high as 2 / s, fully meet the capture speed and complex signals of market demand; Support USB device storage, users can also through the U disk to upgrade software, the greatest degree to meet the needs of the users; Support PictBridge direct print, meet the most extensive printing requirements.
2.Features:
, the new slim design, volume is small and exquisite, carry more convenient;
TFT color LCD display, waveform display more clear and stable;
Rich trigger function: edge, pulse, video, slope, alternate;
Unique digital filtering and waveform recording function;
Pass/Fail function;
, 32 kinds of automatic measurement function;
Reference waveform in the 2 groups, 20 common waveform, 20 group set up internal storage/bring up; Support waveform, Settings, CSV, and bitmap file usb external storage and bring up;
, manual, automatic tracking, the cursor measurement function;
Channel waveforms and FFT wave separately display function at the same time;
Analog channel, the waveform of brightness and screen mesh brightness is adjustable;
Popup menu display mode, the user operation more flexible and natural;
Rich interface display style: classical, modern, traditional, simple;
Multilingual interface display, online help system in both English and Chinese;
Standard configuration interface: USB Host: support U disk storage and can through the USB system software upgrade; USB Device: support PictBridge direct print and connected to the PC remote control; The RS - 232.
3.The technical specifications
Bandwidth: 100MHZ
Channel: channel + 1 external trigger
Highest real-time sampling rate, single channel 1 gsa/S, the double channel 500 msa/S
The equivalent sampling rate: 50 gsa/s
Storage depth: single channel 40 k
Rise time: < 3.5 ns
Input impedance: 1 m Ω | | 17 pf
Time base range: 2.5 ns/div - 50 s/div Roll: 100-50 ms s/div
Vertical sensitivity: 2 to 10 mv v/div (order 1-2-5)
Vertical resolution: 8 - bit
Display: TFT 7 inches (178 mm) of liquid crystal display
1.Digital oscilloscope compact design, flexible operation; Using color TFT LCD and pop-up menu displays, implements its ease of use, greatly improving the user's work efficiency. Moreover, ADS1000 series of excellent performance, powerful, affordable. With high cost performance. Gsa ADS1000 real-time sampling rate is as high as 2 / s, fully meet the capture speed and complex signals of market demand; Support USB device storage, users can also through the U disk to upgrade software, the greatest degree to meet the needs of the users; Support PictBridge direct print, meet the most extensive printing requirements.
2.Features:
, the new slim design, volume is small and exquisite, carry more convenient;
TFT color LCD display, waveform display more clear and stable;
Rich trigger function: edge, pulse, video, slope, alternate;
Unique digital filtering and waveform recording function;
Pass/Fail function;
, 32 kinds of automatic measurement function;
Reference waveform in the 2 groups, 20 common waveform, 20 group set up internal storage/bring up; Support waveform, Settings, CSV, and bitmap file usb external storage and bring up;
, manual, automatic tracking, the cursor measurement function;
Channel waveforms and FFT wave separately display function at the same time;
Analog channel, the waveform of brightness and screen mesh brightness is adjustable;
Popup menu display mode, the user operation more flexible and natural;
Rich interface display style: classical, modern, traditional, simple;
Multilingual interface display, online help system in both English and Chinese;
Standard configuration interface: USB Host: support U disk storage and can through the USB system software upgrade; USB Device: support PictBridge direct print and connected to the PC remote control; The RS - 232.
3.The technical specifications
Bandwidth: 100 MHZ
Channel: channel + 1 external trigger
Highest real-time sampling rate, single channel 1 gsa/S, the double channel 500 msa/S
The equivalent sampling rate: 50 gsa/s
Storage depth: single channel 40 k
Rise time: < 3.5 ns
Input impedance: 1 m Ω | | 17 pf
Time base range: 2.5 ns/div - 50 s/div Roll: 100-50 ms s/div
Vertical sensitivity: 2 to 10 mv v/div (order 1-2-5)
Vertical resolution: 8 - bit
Display: TFT 7 inches (178 mm) of liquid crystal display
