518 Standard Densitometer

518 Standard Densitometer thumbnail-1
518 Standard Densitometer photo-1
US$ 1 - 3,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
United States
Brand Name:
X-Rite
Model Number:
518
Contact Supplier Request Quote Chat Now
Shenzhen Pantai Precise Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin United States
Brand Name X-Rite
Model Number 518

Specifications

1.essential for 4-color press operators
adjustments need to be made during the run
3.with functions like trap and prin

Description:

Product Features:

  • Trap feature helps quickly determine whether on-press color shifts may be due to ink rotation.
  • Check for ink consistency through the run with hue-error and grayness features—evaluate the extent of color contamination or dirtiness
  • Establish optimum density levels and objectively assess shadow detail with industry-standard print contrast feature
  • Quickly and easily measure any color bar—the built-in EFS function selects the proper feature (density, dot, trap, print contrast) based on the patch you measure
  • Upgrade using a keycode to add new features like color or spectral data
  • Only X-Rite lets you select a measurement aperture—microspot 1.6 x 3.2mm, small 2.0mm, medium 3.4mm or large 6.0mm

Specifications:

Measurement Geometry
45°/0° per ANSI & ISO Standards
Spot Size at Sample
3.4mm (.13in) standard
2mm (.078in) optional
6mm (.236in) optional
1.6mmH (.051 in.) x 3.2mmW
(.102 in.) Micro-Spot optional
Light Source
Gas Pressure @ 2856°
Response Types
T, E, I, A, G,Tx, Ex, Hi-Fi
Measurement Range
0.00D–2.5D; 0–160%R
Measurement Time
Approx. 1.4 seconds, approx. .9 seconds for consecutive measurements in Speed Read mode
Warm Up Time
None
Repeatability
±0.005D 0–2.0D*
±0.010D 2.0–2.5D*
*Polarized Yellow ±0.010 0–1.8D
Micro-Spot ±0.010D 0.0–1.8D
Inter-Instrument Agreement
0.01D or 1% for typical printing processes
Data Interface
RS-232 serial interface with baud rates from 1200 to 57.6K communication
Power Source
Ni-MH battery pack, 4.8v r
518 standard Densitometer
