Heat Resistant Combined Flexible Duct

  heat resistant combined flexible duct

- First two meters of heat resistant combined flexible duct is made of heat resistant fiberglass which can be connected to the heating units with high temperature of -70 to +300°C.

-Balance eight meters is made of fire-resistant PVC coated fabric, which temperature range is -20 to +100°C

-Available size: 4"~60"(100mm~1500mm), standard length is 5m /10m, customized length is upon request.

-Color:black and yellow.

-Structure:

one end is bugle with rope, the other end is the steel collar.

yellow pvc coated part

the spiral steel wire wrapped by black rubber strip is hot glue stuck onto the fabric.

black fiberglass part

using the sawing craft to stitch the spiral steel wire with rubber strip onto the fabric.

-Features: 1. heat resistant, wear and tear proof, corrosion resistant and anti-aging.

               2. enduring temperature range of -70 to +300celsius.

                 3.Flexible and light weight for easy use and installation. Rolls up for easy transportation and storage.

Application

with the heating equipment:

1.Widely used for paint drying, food drying and heating in the area of little air flow.

2.for heating in factory, oil field, power plant, steelworks and mine.

3.used for heating in winter and preheating of the machine.

Package: 1pc/ctn, neutral carton packing and special color carton packing as request.

 -Delivery day: 15-20 days after cfm the order.

 -Payment Term: 50%T/T before production, 100% T/T before shipment.

neutral carton

-OEM service is available, R&D department would serve on customer's special ideas.
