used car diagnostic scanner F3-G Global Car and Truck Diagnostic Scanner

1. Products with Main Unit, Diagnostic Connectors, Testing Cables and other accessories attached
2. Overall size with Extra protection box) for 1pcs: 54CM*52CM*19CM ;
Overall size with Extra protection box) for 2pcs: 54CM*52CM*35CM
3. Weight: 1pcs: 11kg
2pcs: 22KG

Specifications

F3-G used car diagnostic scanner
1.Free upgrade
2,Qucik Communication speed
3,Multi-language

Detailed Product Description

FCAR F3-G - Cars and Trucks (12V~24V) Universal F3-G Global Car and Truck Diagnostic Scanner



1.Quick diagnostic speed

2.Online software update

3.Wide vehicle coverage

4.Unique universal scanner





FCAR F3-G - used car diagnostic scanner

 FCAR-F3-G is the newest version of multi-functional intelligentzed gasoline and diesel  universal auto diagnostic scanner. F3-G is the only auto diagnostic scanner that can test both gasoline and heavy duty trucks in one machine.it is including F3-W and F3-D all functions.



Product Introduction:

Testing the global mainstream gasoline cars, heavy duty truck, diesel vehicles, reaching to the same effect with the OEM scanners. Built-in high and low speed CAN-BUS,one diagnostic connector can test all the CAN-BUS vehicles. Support almost all OBD-II protocols.



Vehicle Support:

FOR Gasoline:



For Heavy duty trucks:

Man, Scania, Mitsubishi, Isuzu, MACK, Catepillar, HINO, VOLOV, BENZ, NISSAN UD, Hitachi, Renault, and almost all Chinese Heavy duty trucks /BUS.........



Engine Support:





ECU Support:





Functions

Readout DTC, Readout Engine Model, Readout Computer Edition Information, Readout QR code, Readout System parameter number, Readout Data Stream, Clear DTC, Read-in QR Code, Component test, Break Cylinder Test, Compression Test, Injector Test, Maintenance Help, Study on line and so on.



Product Interface:

1.

2.

3.

 4.

 5.



Host Parameters:

Host Parameters
01	CPU	SAMSUNG ARM2410A,203MHZ
02	SD card interface	insert/ pull out high-capacity SD card
03	Work Power	DC9-28v/3A
04	Port	DB15
05	Memory	2G
06	Display	8-inch TFT LCD touch display true color
07	Resolution	800X600, 16 bit true color  color 65535
08	Print model	58mm thermo printer
09	External Dimension	290.7×207.3×45mm
10	Storage temperature	-30~45°C
11	Operating Temperature	-10~45°C
12	Humidity	<90°C
