Help CenterTwo-Color Pad Printing Machine
Related Products
-
ILC- PM2-150/2Pndependent Up/down Stroke and 2-color Pad Printer LC- PM2-150/2PUS$ 2,990 - 3,100MOQ: 1 Set -
Pneumatic Semi-automatic 2-color Pad Printing Machine With Shutte LC-PM2-200TUS$ 3,000 - 3,500MOQ: 1 Set
-
Luen Cheong Semi Automatic Pneumatic 2 Color Sealed in Cup Tampo Printing Machine for Garment LC-PM2-100-2PTUS$ 2,600 - 3,000MOQ: 1 Set
-
Pneumatic Semi-automatic 2-color Pad Printer With Shutte LC-PM2-200TUS$ 3,000 - 3,500MOQ: 1 Set
-
Pneumatic Semi-automatic 2 Color Pad Printer With Conveyor LC-SPM2-200/10TUS$ 4,000 - 4,500MOQ: 1 Set
Specifications
1.Separate adjustment of the pad up/down stroke speed.2. Ink scraper is auto balance keeping in printing.
1. Controlled by microprocessor, easy operation, running stably and accurately.
2.4-digit auto counter built-in.
3. Cast aluminum machine frame, low weight and high intensity, turnable machine head.
4. Separate adjustment of the pad up/down stroke speed.
5. Ink scraper is auto balance keeping in printing.
6. With the function of ink scraping nonstop without printing in order to prevent ink from drying.
7. Ink cup is turnable and adjustable in vertical and horizontal direction.
8. Super long slide stroke to print large size workpiece.
9. Speed of every single pneumatic organ is adjustable.
1. Model No. LC-PM2-100
2. Printing Colors: 2
3. Plate area: 100*100 mm2
4. Max Printing area: 85*85 mm2
5. Max printing speed: 1400PCS/H
6. Printing Wattage: 220V/ 50Hz 110V/60Hz
7. Air pressure: 0.4-0.6Mpa
8. Machine size: 860x470x1480mm
1. Model No. LC-PM2-150
2. Printing Colors: 2
3. Plate area: 100*150 mm2
4. Max Printing area: 85*135 mm2
5. Max printing speed: 1400PCS/H
6. Printing Wattage: 220V/ 50Hz 110V/60Hz
7. Air pressure: 0.4-0.6Mpa
8. Machine size: 860x470x1480mm
1. Model No. LC-PM2-200
2. Printing Colors: 2
3. Plate area: 100*200 mm2
4. Max Printing area: 85*185 mm2
5. Max printing speed: 1400PCS/H
6. Printing Wattage: 220V/ 50Hz 110V/60Hz
7. Air pressure: 0.4-0.6Mpa
8. Machine size: 860x470x1480mm
1. Model No. LC-PM2-250
2. Printing Colors: 2
3. Plate area: 150*300 mm2
4. Max Printing area: 135*285 mm2
5. Max printing speed: 1400PCS/H
6. Printing Wattage: 220V/ 50Hz 110V/60Hz
7. Air pressure: 0.4-0.6Mpa
8. Machine size: 860x470x1480mm
Machine fitting:
1. Two pcs steel plate
2. Two pcs rubber pad
3. Two pcs jig
4. Work box
5. English operating instruction
Price Terms --FOB or CFR
Payment Terms--- T/T or LC
Packing ----wooden crate
Lead Time ----5 days after confirm Payment
SKU ----10 SETS
Standards Certificate ---CE
Cubic Meter---- 1.4
Gross Weight ---150KG
Main Parts ----FESTO cylinder made by Germany
Application area -----toys, pens, keyboard, plastic products, laber, hardware
